聚醚有机硅表面活性剂与经典阴离子表面活性剂复配体系

doi:10.3969/j.issn.2097-2806.2024.10.002

摘要/Abstract

摘要：

聚醚有机硅表面活性剂因其良好的表面活性近年来受到广泛关注。为了进一步扩展其下游应用空间，开发复合表面活性剂配方，文章将一种寡聚醇聚醚三硅氧烷表面活性剂与经典阴离子表面活性剂（烷基糖苷磺酸盐和醇醚磷酸盐）复配，详细探究了二元表面活性剂混合体系的混合吸附参数和混合胶束参数。随后围绕精选的复配比例，对二元表面活性剂的分散（泡沫、乳液、悬浮液）性能在常见模型体系中进行了初步探究，为聚醚硅表面活性剂体系的应用开发提供了重要的基础参考。

关键词: 表面活性, 阴-非离子表面活性剂复配, 分散性能

Abstract:

Polyether organosilicon surfactants have received widespread attention in recent years due to their excellent surface activities. To further expand the downstream application and develop a surfactant formula, in this work, a polyether modified trisiloxane surfactant was mixed with a classical anionic surfactant （alkyl glycoside sulfonate or fatty-alcohol polyethoxylate phosphate）, and the mixed adsorption parameters and mixed micellization parameters of the binary surfactant mixtures were investigated in detail. For the selected mixing ratio, the dispersing performance of binary surfactant mixtures was evaluated in common model systems （foam, emulsion, suspension）, which could provide an important reference for the application and development of systems of polyether modified silicone surfactants.

Key words: surface activity, mixture of anionic and nonionic surfactants, dispersion

中图分类号:

TQ423

梁馨支, 孙婷, 叶馨遥, 王宇凯, 白亮, 李洪光. 聚醚有机硅表面活性剂与经典阴离子表面活性剂复配体系[J]. 日用化学工业（中英文）, 2024, 54(10): 1155-1165.

Xinzhi Liang, Ting Sun, Xinyao Ye, Yukai Wang, Liang Bai, Hongguang Li. Study on the mixed systems of polyether organosilicon surfactant and classic anionic surfactants[J]. China Surfactant Detergent & Cosmetics, 2024, 54(10): 1155-1165.

图/表 11

图1

图2

表1

表2

表3

图3

表4

图4

图5

图6

图7

参考文献 32

[1]	Cho Jangwhan, Yoon Seongwon, Min Sim Kyu, et al. Universal selection rule for surfactants used in miniemulsion processes for eco-friendly and high performance polymer semiconductors[J]. Energy & Environmental Science, 2017, 10 (11) : 2324-2333.
[2]	Tanaka Motomu, Krafft Marie Pierre, Pasc Andreea. Higher-order mesoscopic self-assembly of fluorinated surfactants on water surfaces[J]. NPG Asia Materials, 2023, 15 (1) : 23-36.
[3]	Jena Gyanaranjan, Dutta Kasturi, Daverey Achlesh. Surfactants in water and wastewater (greywater): Environmental toxicity and treatment options[J]. Chemosphere, 2023, 341: 140082.
[4]	Inès Mnif, Mouna Bouassida, Marwa Elghoul, et al. Biosurfactants as emerging substitutes of their synthetic counterpart in detergent formula: efficiency and environmental friendly[J]. Journal of Polymers and the Environment, 2023, 31 (7) : 2779-2791.
[5]	Yin Danna. Synthesis and properties of polyether modified trisiloxane surfactant[D]. Guangzhou: Guangzhou University, 2011.
[6]	Zhang Bo, Wu Tong, Zhao Fuhua, et al. Application and green development of silicon containing surfactants[J]. Chemical Technology Market, 2010, 33 (5) : 29-32.
[7]	Kong Xiangshuang. Synthesis and performance study of new organosilicon surfactants[D]. Qingdao: China University of Petroleum (East China), 2014.
[8]	Sfameni Silvia, Rando Giulia, Plutino Maria Rosaria. Sustainable secondary-raw materials, natural substances and eco-Friendly nanomaterial-based approaches for improved surface performances: An overview of what they are and how they work[J]. International Journal of Molecular Sciences, 2023, 24 (6): 5472.
[9]	Xu Aoxue, Liu Hailong, Yi Gang, et al. Clustering-enhanced, nonconventional photoluminescence from a silicone surfactant[J]. Chemical Communications, 2023, 59 (24) : 3558-3561. doi: 10.1039/d2cc06428f pmid: 36880229
[10]	Jiang Luming, Song Zhaozheng, Tan Guorong, et al. Application progress of surfactant compounding in tertiary oil recovery[J]. Guangzhou Chemical Industry, 2014, 42 (3) : 9-11.
[11]	Kao Feifei. Study on the surface activity and intermolecular interactions of mixed systems of anionic surfactants[D]. Jinan: Shandong Normal University, 2012.
[12]	State Administration for Market Regulation; Standardization Administration of China. Determination method of suspensibility for pesticides: GB/T 14825—2023[S]. Beijing: State Administration for Market Regulation; Standardization Administration of China, 2023: 16.
[13]	Zhang Xiuna, Wang Haifeng. Synthesis and application of fatty alcohol polyoxyethylene ether phosphate[J]. Detergent & Cosmetics, 2011, 34 (7) : 24-27.
[14]	Yang Yongnian, Wen Pengpeng, Guo Jianguo, et al. Differentiation of downstream derivatives of narrow distribution alcohol ethers[J]. Detergent & Cosmetics, 2016, 39 (8) : 39-42.
[15]	Rosen Milton J, Sulthana Sulthana B. The interaction of alkylglycosides with other surfactants[J]. Journal of Colloid and Interface Science, 2001, 239 (2) : 528-534. pmid: 11427020
[16]	Stellner K Kevin L, Amante Joel C, Scamehorn John F, et al. Precipitation phenomena in mixtures of anionic and cationic surfactants in aqueous solutions[J]. Journal of Colloid and Interface Science, 1988, 123 (1) : 186-200.
[17]	Sanan Reshu, Mahajan R K. Effect of fatty acid chain of tweens on the micellar behavior of dodecylbenzyldimethylammonium chloride[J]. Industrial & Engineering Chemistry Research, 2011, 50 (12) : 7319-7325.
[18]	Li Xiuzhi, Zhao Jianxi. Effect of quaternary ammonium Gemini surfactant C₁₂-6-C₁₂·2Br on the micellization of SDS in aqueous solution[J]. Chinese Journal of Applied Chemistry, 2003, 20 (7) : 690-692.
[19]	Rub Malik Abdul, Asiri Abdullah M, Naqvi Andleeb Z, et al. Mixed micellization between amphiphilic drug promethazine hydrochloride and cationic surfactant (conventional as well as Gemini)[J]. Journal of Molecular Liquids, 2013, 177: 19-25.
[20]	Zhou Qiong, Wu Yongfu, Rosen Milton J. Surfactant-surfactant molecular interactions in mixed monolayers at a highly hydrophobic solid/aqueous solution interface and their relationship to enhanced spreading on the solid substrate[J]. Langmuir, 2003, 19 (19) : 7955-7962.
[21]	Ren Zhaohua, Huang Jing, Zheng Yancheng, et al. Effect of isopropanol on the micellization of binary mixture containing amino sulfonate amphoteric surfactant in aqueous solution: Mixing with octylphenol polyoxyethylene ether (7)[J]. Journal of Molecular Liquids, 2017, 236: 101-106.
[22]	Zhao Ting, Feng Ning, Zhao Yonghong, et al. Adsorption properties and aggregation behavior of mixed system of anionic/cation surfactants with different structures[J]. Journal of Molecular Liquids, 2021, 337: 116341.
[23]	Feng Ning, Zhang Bo, Xin Xia, et al. Role of aliphatic alcohol polyoxyethylene ether phosphate in 25 wt% tebuconazole suspension concentrate: Dispersion and wetting[J]. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2021, 628: 127350.
[24]	Lisi R De, Lazzara G, Lombardo R, et al. Thermodynamic behavior of nonionic tri-block copolymers in water at three temperatures[J]. Journal of Solution Chemistry, 2006, 35 (5) : 659-678.
[25]	Tsui Hungwei, Wang Jinghan, Hsu Yahui, et al. Study of heat of micellization and phase separation for Pluronic aqueous solutions by using a high sensitivity differential scanning calorimetry[J]. Colloid & Polymer Science, 2010, 288 (18) : 1687-1696.
[26]	Zhao Hongkai, Xiao Wenqi. Research progress in the mechanism of surfactant stabilizing foam[J]. Applied Chemical Engineering, 2019, 48 (5) : 1167-1171.
[27]	Zhao Hui, Bai Yanyun, Sun Haoyang, et al. Study of the molecular array behaviours and interfacial activities of green surfactant alkyl polyglycoside and the mixed systems with other surfactants on oil-water interface[J]. Molecular Simulation, 2017: 1107-1115.
[28]	Luo Xiaoqiang, Li Shihan, Wu Jimin. The influence of hydrophilic and hydrophobic values on the performance of organosilicon defoamers[J]. Chemical Engineer, 2016, 30 (7) : 82-83, 27.
[29]	Liu Hongguo, Sun Dejun, Hao Jingcheng. New compilation of colloids and interface chemistry[J]. Analytical Chemistry, 2016, 44 (12): 1807.
[30]	Fisher L R, Mitchell E E, Parker N S. Interfacial tensions of commercial vegetable oils with water[J]. Journal of Food Science, 2010, 50 (4) : 1201-1202.
[31]	Hammond-Pereira Ellis, Zhang Xianghui, Wu Di, et al. Precise tuning of silica pore length and pore diameter on silica-encapsulated gold core-shell nanoparticles and catalytic impact[J]. Chemical Engineering Journal, 2023, 475: 146043.
[32]	Zhang Yaheng, Tang Zhiyong. Study on the hydraulic classification characteristics of micron-sized silica particles[J]. Asia-Pacific Journal of Chemical Engineering, 2023, 18 (5): e2966.

	α₁^*	cmc/ （mol/L）	γ_cmc/ （mN/m）	pc₂₀	Г_max/ （μmol/m²）	A_min/nm²	cmc _ideal/ （mol/L）	Γ_{max, ideal}/ （μmol/m²）	A_{min, ideal}/nm²
APG-SS/PTS	1	4.15×10^-4	31.78	3.15	4.58	0.36
	0.8	3.56×10^-4	25.46	5.12	2.68	0.62	3.067×10^-4	2.99	0.55
	0.5	3.18×10^-4	21.97	5.22	2.29	0.73	2.204×10^-4	2.85	0.58
	0.2	1.85×10^-4	21.79	5.39	2.37	0.70	1.720×10^-4	2.75	0.60
	0	1.50×10^-4	21.42	5.58	2.48	0.67
AEP-K/PTS	1	3.05×10^-5	39.91	5.26	3.34	0.50
	0.8	3.89×10^-5	39.70	5.04	3.47	0.48	3.594×10^-5	3.001 8	0.55
	0.5	4.49×10^-5	38.96	5.20	1.98	0.84	5.028×10^-5	2.595 0	0.64
	0.2	1.14×10^-4	30.91	5.31	2.19	0.76	8.364×10^-5	2.564 1	0.65
	0	1.50×10^-4	21.42	5.58	2.48	0.67

	α₁^*	X^m₁	β^m	f ^m₁	f ^m₂	X^σ₁	β^σ	f ^σ₁	f ^σ₂
APG-SS/PTS	0.8	0.562	-4.970	0.386	0.208	0.373	-7.593	0.051	0.347
	0.5	0.209	-4.035	0.080	0.839	0.285	-8.642	0.012	0.495
	0.2	0.190	-6.214	0.017	0.799	0.212	-9.535	0.003	0.652
AEP-K/PTS	0.8	0.752	-8.122	0.608	0.010	0.678	-2.632	0.761	0.299
	0.5	0.678	-6.601	0.504	0.048	0.172	-4.217	0.056	0.882
	0.2	0.547	-4.310	0.413	0.275	0.127	-6.044	0.010	0.907

	α₁	ΔG_{mic, ideal}/ （KJ/mol）	ΔG_mic/ （KJ/mol）	ΔH_mic/ （KJ/mol）	TΔS_mic/ （KJ/mol）
APG-SS/PTS	0.8	-1.699	-4.731	-3.032	1.699
	0.5	-1.270	-2.923	-1.653	1.270
	0.2	-1.205	-3.574	-2.369	1.205
AEP-K/PTS	0.8	-1.387	-5.137	-3.75	1.387
	0.5	-1.558	-5.132	-3.574	1.558
	0.2	-1.707	-4.354	-2.647	1.707

样品名称	n	t^*/s	t_i/s	t_m/s	R_1/2/（mN/（m·s））
APG-SS/PTS	0.352	0.372	5.37×10^-4	258	50.86
AEP-K/PTS	0.417	0.023	9.41×10^-5	5.89	804.78
