高效液相色谱-三重四极杆质谱法测定化妆品中的西咪替丁及雷尼替丁

doi:10.3969/j.issn.1001-1803.2020.09.011

摘要/Abstract

摘要：

建立可同时测定化妆品中西咪替丁及雷尼替丁的高效液相色谱-三重四极杆质谱方法。待测样品经甲醇超声提取,经0.2 μm滤膜过滤后进样检测,在优化的色谱、质谱条件下,经ZORBAX SB-Aq色谱柱分离。采用电喷雾离子源在正离子模式下进行多反应监测。用基质匹配外标曲线法进行定量分析。结果表明,西咪替丁、雷尼替丁的检出浓度分别为0.03和0.02 ng/g,在1~100 ng/mL范围内线性关系良好（r >0.999）,低、中、高3个质量浓度水平下的样品加标回收率为84.9%~116.2%,RSD不超过5%。建立的方法前处理过程简单,灵敏度、线性、回收率及重复性均满足方法学要求,可同时对化妆品中的西咪替丁和雷尼替丁进行测定。

关键词: 化妆品, 西咪替丁, 雷尼替丁, 抗组胺, 高效液相色谱-三重四极杆质谱法

Abstract:

A high performance liquid chromatography-tandem mass spectrometric method was established for determination of cimetidine and ranitidine in cosmetics. Samples were extracted by methanol ultrasonically, and then filtered through a 0.2 μm membrane. After separated by a ZORBAX SB-Aq column, samples were detected by MRM with electrospray ion source in positive mode. Matrix-matched external standard calibration curves were used for quantitative analysis. The concentration limits of detection of cimetidine and ranitidine were 0.03 and 0.02 ng/g, respectively. In the mass concentration range of 1-100 ng/mL, cimetidine and ranitidine showed good linear relationship with correlation coefficients all above 0.999．The recoveries for cimetidine and ranitidine at three spiked levels were in the range of 84.9%-116.2%, and the relative standard deviations of their recoveries were not more than 5%. This method was able to be applied in determination of cimetidine and ranitidine in cosmetics with simple pretreatment, good linearity and high recovery.

Key words: cosmetics, cimetidine, ranitidine, antihistamine, high performance liquid chromatography-tandem mass spectrometric method

中图分类号:

TQ658

王聪,李莉,王海燕,孙磊. 高效液相色谱-三重四极杆质谱法测定化妆品中的西咪替丁及雷尼替丁[J]. 日用化学工业, 2020, 50(9): 643-647.

WANG Cong,LI Li,WANG Hai-yan,SUN Lei. Determination of cimetidine and ranitidine in cosmetics by high performance liquid chromatography-tandem mass spectrometry[J]. China Surfactant Detergent & Cosmetics, 2020, 50(9): 643-647.

图/表 7

表 1

表 2

图 1

图 2

表 3

图 3

表 4

参考文献 16

[1]	Ashiru D, Patel R, Basit A W . Simple and universal HPLC-UV method to determine cimetidine, ranitidine, famotidine and nizatidine in urine: Application to the analysis of ranitidine and its metabolites in human volunteers[J]. Journal of Chromatography B, 2007,860(2) : 235. doi: 10.1016/j.jchromb.2007.10.029
[2]	Hatwal A, Bhatt R P, Agrawal J K , et al. Spironolactone and cimetidine in treatment of acne[J]. Acta Dermato Venereologica, 1988,68(1) : 84-87. pmid: 2449021
[3]	Meng W . Analysis of clinical curative effect of the treatment of facial herpes simplex virus by cimetidine injection[J]. Heilongjiang Medicine Journal, 2016,29(4) : 683-684.
[4]	Deng M, Liao Y M, Liu H J . The clinic efficacy of acitretin combined with dipyridamole and cimetidine in the treatment of flat wart[J]. Chinese Journal of Clinical Rational Drug Use, 2016,9(2) : 13-14.
[5]	Luo Z Z . Efficacy of cimetidine in treatment of facial herpes simplex[J]. China Health Standard Management, 2016,7(1) : 104-105.
[6]	Wang G L, Zhang Q S. Comparison of global cosmetic technology regulations [M]. Beijing: People’s Medical Publishing House, 2018.
[7]	Expert Committee on Cosmetic Standards of the State Food and Drug Administration. Safety and technical standards for cosmetics [M]. Beijing: People’s Medical Publishing House, 2017.
[8]	Wu S M, Ho Y H, Wu H L , et al. Head-column field-amplified sample stacking in capillary electrophoresis for the determination of cimetidine, famotidine, nizatidine, and ranitidine-HCl in plasma[J]. Electrophoresis, 2015,22(13) : 2717-2722. doi: 10.1002/1522-2683(200108)22:13<2717::AID-ELPS2717>3.0.CO;2-2 pmid: 11545397
[9]	Zhang X L, Wang C, Wang Y H , et al. Determination of cimetidine in tablets by NMR[J]. Chemical Analysis and Meterage, 2016,25(4) : 19-22.
[10]	Chang Y X, Qiu Y Q, Du L M , et al. Determination of ranitidine, nizatidine, and cimetidine by a sensitive fluorescent probe[J]. The Analyst, 2011,136(20) : 4168. doi: 10.1039/c1an15078b pmid: 21858296
[11]	Yang Q, Lin J Y, Guo D , et al. Determination of cimetidine in rat plasma by HPLC[J]. Strait Pharmaceutical Journal, 2017,29(3) : 42-44.
[12]	Shen L P . Content determination of cimetidine tablets and related substances by HPLC[J]. Strait Pharmaceutical Journal, 2018,30(1) : 80-83.
[13]	Majidano S A, Khuhawar M Y . GC Determination of famotidine, ranitidine, cimetidine, and metformin in pharmaceutical preparations and serum using methylglyoxal as derivatizing reagent[J]. Chromatographia, 2012,75(21/22) : 1311-1317. doi: 10.1007/s10337-012-2321-6
[14]	Qiu Y, Chang Y, Du L , et al. Fluorescence probe method for determination of ranitidine, nizatidine and cimetidine[J]. Chinese Journal of Pharmaceutical Analysis, 2012,32(6) : 973-977.
[15]	National Medical Products Administration. Bulletin of the National Medical Products Administration on determination of cimetidine in cosmetics(2019 No.148)[EB/OL].(2019-08-15)[2019-12-19]. https://www.nmpa.gov.cn/hzhp/hzhpggtg/hzhpqtgg/20190815175801389.html.
[16]	Li Z G, Ren N, Ma Y H , et al. Determination of illegal water-retaining drugs in frozen meat by UPLC-MS/MS[J]. Food Science, 2018,577(12) : 308-312.

时间/min	φ（A）/%	φ（B）/%
0	95	5
6	10	90
9	10	90
9.1	95	5
12	95	5

化合物	保留时间/min	母离子	定量离子	定性离子	碰撞能量/V
西咪替丁	3.3	253.1	117.0	117.0;159.2	32;42
雷尼替丁	3.4	315.1	176.1	176.1;130.1	28;42

化合物	基质	回归方程	相关系数	线性范围/(ng·mL^-1)	基质效应/%
西咪替丁	无	y=377x-629	0.999 6	1.13~113
	液态水基	y=214x+59	0.999 8	1.13~113	-43.2
	膏霜	y=282x-187	0.999 8	1.13~113	-25.2
	乳液	y=313x+212	0.999 8	1.13~113	-17.0
雷尼替丁	无	y=575x+306	0.999 9	0.990~99.0
	液态水基	y=229x+28	0.999 8	0.990~99.0	-60.2
	膏霜	y=439x+68	0.999 9	0.990~99.0	-23.7
	乳液	y=461x+908	0.999 6	0.990~99.0	-19.8

化合物	基质	回收率/%			回收率RSD/%			重复性RSD/%
化合物	基质	低浓度	中浓度	高浓度	低浓度	中浓度	高浓度	重复性RSD/%
西咪替丁	乳液	98.0~103.6	89.8~93.5	99.0~100.4	3.0	2.0	0.8	3.5
	膏霜	107.6~116.2	85.8~90.8	96.2~99.1	4.0	2.9	0.9	1.4
	液态水基	99.0~100.4	89.5~91.0	95.2~96.2	0.9	1.7	0.5	3.9
雷尼替丁	乳液	84.9~90.8	100.3~113.5	109.3~113.7	3.4	1.6	2.1	2.3
	膏霜	101.5~105.7	106.8~115.9	106.5~110.6	2.0	4.1	1.9	1.0
	液态水基	97.8~108.1	104.1~108.3	104.5~107.6	5.0	2.2	1.6	6.9
