新型乳化体系及其在化妆品中的应用（I）——液晶乳化体系

doi:10.3969/j.issn.2097-2806.2023.09.003

摘要/Abstract

摘要：

液晶乳化体系是一种新型的乳化体系，体系中表面活性剂（乳化剂）分子在油、水界面定向排列，形成长程有序、短程无序的液晶结构（通常为层状液晶）。乳化剂形成的层状液晶与皮肤角质层结构相似，使其在化妆品、生物医学等领域有着广阔的应用前景。随着人们对液晶认知的不断深入，以及消费者对液晶乳化产品优势的逐步认可，液晶乳化体系在高端化妆品中正得到广泛的应用。本文首先介绍了液晶及液晶乳化体系，总结了影响液晶乳化体系中液晶形成的因素以及液晶乳化产品的性能，包括稳定性、锁水保湿性能、包裹、缓释及促渗透性能和肤感等。在此基础上，阐述了液晶乳化体系在化妆品领域的应用，并对近年开发的特殊液晶乳化体系——液晶包结晶乳化体系、多重液晶乳化体系进行了介绍。最后指出了现阶段液晶乳化体系在化妆品领域应用的局限性，并对亟待解决的问题提出了个人看法，旨在为液晶乳化体系的开发及有效应用提供参考。

关键词: 液晶乳化体系, 化妆品, 产品性能

Abstract:

Liquid crystal emulsion system is a new type of emulsion system, in which the surfactant （emulsifier） molecules locate at the oil/water interface and form a long-range ordered and short-range disordered liquid crystal structure （usually lamellar liquid crystal）. The lamellar liquid crystals formed by emulsifier are similar to the skin stratum corneum lipid structure, which enable it a broad application prospect in the field of cosmetics, biomedicine, etc. With the further understanding of the liquid crystal and the gradual recognition of the advantages of liquid crystal emulsion products, the liquid crystal emulsion system has been used in high-end cosmetics widely in the past few years. In this paper, the liquid crystal and the liquid crystal emulsion system are introduced firstly and then the factors of affecting the formation of liquid crystal in emulsions are summarized. The properties of liquid crystal emulsion systems including the stability, water locking property, sustained-release property, penetration enhancing property as well as the skin sense are also provided. On this basis, the application of liquid crystal emulsion system in the cosmetic field is expounded. Furthermore, the novel liquid crystal emulsion system developed in recent years, including crystal encapsulated in liquid crystal emulsion and multiple liquid crystal emulsion are introduced. Finally, the limitations of the application of liquid crystal emulsion system in the field of cosmetics are put forward and personal views on the problems to be solved are proposed, which may provide necessary reference for the development and effective application of liquid crystal emulsion system.

Key words: liquid crystal emulsion system, cosmetics, product performance

中图分类号:

TQ658

周康夫, 晏佳怡, 尚亚卓. 新型乳化体系及其在化妆品中的应用（I）——液晶乳化体系[J]. 日用化学工业（中英文）, 2023, 53(9): 1008-1017.

Zhou Kangfu, Yan Jiayi, Shang Yazhuo. New emulsion system and its application in cosmetics （I）Liquid crystal emulsion system[J]. China Surfactant Detergent & Cosmetics, 2023, 53(9): 1008-1017.

图/表 10

图 1

图 2

图 3

图4

图 5

图 6

图 7

图 8

图 9

图 10

参考文献 46

[1]	Jia Yanmei. Emulsion cosmetics[J]. China Cosmetics Review, 2009 (4) : 76-82.
[2]	Yuan Minjia, Wang Fei, Zhang Lihua, et al. Influence of formulation ingredients and physicochemical environment on formation of liquid crystal in alkyl polyglucoside system[J]. China Surfactant Detergent & Cosmetics, 2016, 46 (2) : 84-88.
[3]	Oliveira L B A, Oliveira R, Oliveira C, et al. Cosmetic potential of a liotropic liquid crystal emulsion containing resveratrol[J]. Cosmetics, 2017, 4 (4): 54. doi: 10.3390/cosmetics4040054
[4]	Wang Ke. Study on the mechanism and application of hydrogenated lecithin to form liquid crystal[D]. Shanghai: Shanghai Institute of Technology, 2018.
[5]	Yuan Minjia. Study on the formation of liquid crystal structure by using an olive oil derived emulsifier Olivem 1000[J]. Flavour Fragrance Cosmetics, 2021 (3) : 97-100, 104.
[6]	Meier G. Book review: handbook of liquid crystals[J]. Angewandte Chemie International Edition in English, 1980, 19 (8) : 656-656.
[7]	Hedge R M, Thomas R K, Mortimer M, et al. Structure of the amellar lyotropic liquid crystal, tetramethylammonium perfluorooctanoate+water, determined by neutron diffraction[J]. Journal of the Chemical Society, Faraday Transactions, 1980, 76 (4) : 236-243.
[8]	Fei Lun, Wei Hu. New progress in the research of the physical aase and its functional characteristics of the meridian[C]// The 4th Symposium on Clinical and Scientific Research of Acupuncture, Shanghai, China, 2002.
[9]	Braganza L F, Dubois M, Tabony J. Stabilization of lamellar oil-water liquid crystals by surfactant/co-surfactant monolayers[J]. Nature, 1989, 338: 403. doi: 10.1038/338403a0
[10]	Kimiy, Nakagawa S, Rik, et al. Liquid crystal O/W emulsions to mimic lipids and strength skin barrier function[J]. Cosmetics & Toiletries, 2009, 124 (7) : 64-72.
[11]	Carlotti M E, Sapino S, Gallarate M, et al. Release of mandelic acid from O/W emulsions with lamellar phases[J]. Journal of Dispersion Science and Technology, 2008, 29 (10) : 1460-1470. doi: 10.1080/01932690802313592
[12]	Terescenco D, Savary G, Picard C, et al. Influence of the emollient on emulsions containing lamellar liquid crystals: from molecular organization towards applicative properties[J]. International Journal of Cosmetic Science, 2018, 40 (6) : 565-574. doi: 10.1111/ics.12498 pmid: 30303546
[13]	Zhuang Fuping, Zou Qingsong. The preparation method and application of a liquid crystal emulsifier with anti-allergy effects designed by bionic sebum film: CN113509395A [P]. 2021-10-19.
[14]	Li Jinhua. Cosmetic compound containing stable liquid crystal structure and preparation method of cosmetic compound: CN112190488A[P]. 2020-10-26.
[15]	Xie Yong, Liu Yujiao, Wang Yaqin, et al. A layered liquid crystal moisturizing cream and its preparation method: CN107233218A[P]. 2017-06-20.
[16]	Zhao Hongwei. A liquid crystal emulsion and its preparation method: CN108670905A[P]. 2018-07-17.
[17]	Zhou Meng. Development and application of high efficiency compound liquid crystal emulsifier[D]. Shanghai: East China University of Science and Technology, 2018.
[18]	Liu Huimin, Ma Xiaoyuan, Zhao Yonghong. Preparation of liquid crystal emulsion and its application in cosmetics[J]. China Surfactant Detergent & Cosmetics, 2022, 52 (7) : 762-769.
[19]	Fang Yun, Shen Xiaoqin, Lu Jie, et al. Influence of co-emulsifier on stability and liquid crystal status of cosmetic emulsion[J]. China Surfactant Detergent & Cosmetics, 2002, 3 (1) : 8-11.
[20]	Teng Hongni, Teng Dawei. The effect of fatty alcohol on the stability of liquid crystal emulsion[J]. Journal of Qingdao University, 1997 (3) : 1-4.
[21]	Guo Rong. The effects of chain length of straight chain alcohol on the structure and stability of lamellar liquid crystal[J]. Acta Physico Chimica Sinica, 1991 (6) : 703-707.
[22]	Guo Rong, Yan Pengquan, Zhu Xiashi, et al. The structure and stability of lameller liquid crystal with short chain alcohol[J]. Journal of Applied Sciences, 1994 (3) : 233-238.
[23]	Zhang Wanping, Zhu Liangliang. Effect of emulsification technology on formation of liquid crystals[J]. China Surfactant Detergent & Cosmetics, 2009, 39 (1) : 35-38.
[24]	Ghosh S, Rousseau D. Fat crystals and water-in-oil emulsion stability[J]. Current Opinion in Colloid and Interface Science, 2011, 16 (5) : 421-431. doi: 10.1016/j.cocis.2011.06.006
[25]	Zhou Meng, Shu Peng, Feng Bei, et al. Properties of lecithin liquid crystal emulsion[J]. Chinese Journal of Applied Chemistry, 2018, 35 (10) : 1227-1233. doi: 10.11944/j.issn.1000-0518.2018.10.170333
[26]	Hu Jiajie, Ni Zhuoyao, Zhu Hui, et al. A novel drug delivery system-drug crystallization encapsulated liquid crystal emulsion[J]. International Journal of Pharmaceutics, 2021, 607: 121007-121015. doi: 10.1016/j.ijpharm.2021.121007
[27]	Iwai H, Fukasawa J, SuzukiI T. A liquid crystal application in skin care cosmetics[J]. International Journal of Cosmetic Science, 1998, 20 (2) : 87-102. doi: 10.1046/j.1467-2494.1998.171741.x pmid: 18505494
[28]	Terescenco D, Picard C, Clemenceau F, et al. Influence of the emollient structure on the properties of cosmetic emulsion containing lamellar liquid crystals[J]. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2018, 536: 10-19. doi: 10.1016/j.colsurfa.2017.08.017
[29]	Wang Ye, Li Jiusheng, Shang Yazhuo, et al. Study on the development of wax emulsion with liquid crystal structure and its moisturizing and frictional interactions with skin[J]. Colloids and Surfaces B: Biointerfaces, 2018, 171: 335-342. doi: 10.1016/j.colsurfb.2018.07.039
[30]	Ibrahim H G. Release studies from lyotropic liquid crystal systems[J]. Journal of Pharmaceutical Sciences, 1989, 78 (8) : 683-687. pmid: 2778675
[31]	Aytekin M, Gursoy R N, Ide S, et al. Formulation and characterization of liquid crystal systems containing azelaic acid for topical delivery[J]. Drug Development and Industrial Pharmacy, 2013, 39 (2) : 228-239. doi: 10.3109/03639045.2012.671829 pmid: 22480294
[32]	Patravale V B, Mandawgade S D. Novel cosmetic delivery systems: an application update[J]. International Journal of Cosmetic Science, 2008, 30 (1) : 19-33. doi: 10.1111/j.1468-2494.2008.00416.x pmid: 18377627
[33]	Luu T, Mercier M, Thau P. Sucrose ester multilamellar emulsifiers for skin moisturization[J]. Cosmetics and Toiletries, 2010, 125 (10) : 48-52.
[34]	Imai M, Hashizaki K, Yanagi A, et al. Skin permeation of testosterone from viscoelastic lecithin reverse wormlike micellar solution[J]. Biological and Pharmaceutical Bulletin, 2016, 39 (4) : 532-539. doi: 10.1248/bpb.b15-00750
[35]	Zhang Jie. A moisturizing anti-wrinkle cream with a layered liquid crystal structure and its preparation method: CN114732743A[P]. 2022-07-12.
[36]	Shang Yazhuo, Liu Lijia, Jin Jun, et al. A multi-efficacy liquid crystal emulsion for mask and its preparation method: CN109288687A[P]. 2019-02-01.
[37]	Shang Yazhuo, Liu Yuwen. A full-effect repair lotion for sensitive skin prepared by shea butter and its preparation method: CN113749986 A[P]. 2021-12-07.
[38]	Shang Yazhuo, Sheng Kaiman, Xu Jiawen, et al. Preparation method and application of cosmetics prepared by giant salamander extract: CN116327630A[P]. 2023-06-27.
[39]	Mo Meiling. A highly moisturizing liquid crystal structure sunscreen composition and its preparation method and application: CN114617777A[P]. 2022-06-14.
[40]	Shang Yazhuo, Ren Huanyu, Chen Yinghong, et al. Preparation and application of a sunscreen for sensitive skin: 202310593088.1[P]. 2023-05-24.
[41]	Zhou Lizhen, Fang Ruhui, Zhao Jiasi. A semi-transparent gel liquid crystal hair film and its preparation method: CN113509406A[P]. 2021-10-19.
[42]	Shang Yazhuo, Feng Bei, Li Chengliang. A liquid crystal hair film and its preparation method: CN115569076A[P]. 2023-01-06.
[43]	Shang Yazhuo, Hu Jiajie, Yang Shuqin, et al. A liquid crystal emulsion containing drug crystal and its preparation method: CN112972381B[P]. 2021-06-18.
[44]	Ding Lin, Li Hanglin, Ye Zhicheng, et al. A novel delivery system-liquid crystal emulsion containing HSO crystal[J]. New Journal of Chemistry, 2023, 47: 10576-10584. doi: 10.1039/D3NJ01050C
[45]	Han Xiangyou, Li Minya, Lu Wenzhu, et al. A W/O/W multiemulsion cosmetic composition with low viscosity: CN114129462A[P]. 2022-03-04.
[46]	Lv Yawen, Wang Jingwen, Ye Zhicheng, et al. Preparation of P/O/LC/W multiple emulsion[J]. China Surfactant Detergent & Cosmetics, 2023, 53 (2) : 121-132.
