表没食子儿茶素没食子酸酯脂质体的制备及其透皮性能研究

doi:10.3969/j.issn.1001-1803.2020.09.005

摘要/Abstract

摘要：

采用大豆卵磷脂、胆固醇为壁材,通过薄膜-超声分散法制备了表没食子儿茶素没食子酸酯（EGCG）脂质体（EGCG Liposome,EL）,研究了胆固醇用量、水化温度、超声时间、EGCG添加量对EL粒径、PDI、包封率以及产率的影响。进一步对EL的透皮效果进行研究,并测定了其储藏稳定性。结果表明,在卵磷脂和胆固醇的质量比为1∶0.25,超声时间为6 min,水化温度为50 ℃,EGCG和卵磷脂的质量比为0.075∶1时,EL包封率、产率和粒径都较优,包封率和产率分别为84.75%±2.12%和93.78%±2.16%,粒径为（132.74±1.03） nm,PDI为0.245±0.009。通过透皮和储藏稳定性实验可知,与EGCG水溶液相比,脂质体能显著提高EGCG的透皮运输能力及储藏稳定性。

关键词: 表没食子儿茶素没食子酸酯脂质体, 制备, 透皮运输, 稳定性

Abstract:

Epigallocatechin gallate （EGCG） liposomes （EL） were prepared by membrane-ultrasonic dispersion using soybean lecithin and cholesterol as encapsulation materials. The effects of the amount of cholesterol, hydration temperature, ultrasonic time, EGCG addition amount on the particle size, PDI, entrapment efficiency and yield of EL were studied. Also, the transdermal performance and the storage stability of EL were measured. The results show that, when the mass ratio of lecithin to cholesterol is 1∶0.25, the ultrasonic time is 6 min, the hydration temperature is 50 ℃, and the mass ratio of EGCG to lecithin is 0.075∶1, the high encapsulation efficiency and yield are achieved as 84.75%±2.12% and 93.78%±2.16%, and the particle size is （132.74±1.03） nm, the PDI is 0.245±0.009. According to the storage stability and transdermal experiments, liposomes can improve the transdermal transport and stability of EGCG significantly compared with the EGCG aqueous solution.

Key words: epigallocatechin gallate liposomes, preparation, skin penetration, stability

中图分类号:

TQ658

曹振大,梁蓉. 表没食子儿茶素没食子酸酯脂质体的制备及其透皮性能研究[J]. 日用化学工业, 2020, 50(9): 609-614.

CAO Zhen-da,LIANG Rong. Study on the preparation and transdermal performance of epigallocatechin gallate liposome[J]. China Surfactant Detergent & Cosmetics, 2020, 50(9): 609-614.

图/表 6

图 1

图 2

图 3

图 4

图 5

图 6

参考文献 21

[1]	Guo Q, Zhao B L, Shen S R , et al. ESR study on the structure-antioxidant activity relationship of tea catechins and their epimers[J]. Biochimica Et Biophysica Acta-General Subjects, 1999,1427(1) : 13-23. doi: 10.1016/S0304-4165(98)00168-8
[2]	Krupkova O, Ferguson S J, Wuertz-Kozak K . Stability of (-)- epigallocatechin gallate and its activity in liquid formulations and delivery systems[J]. The Journal of Nutritional Biochemistry, 2016,37:1-12. doi: 10.1016/j.jnutbio.2016.01.002 pmid: 27770867
[3]	Wisuitiprot W, Somsiri A, Ingkaninan K , et al. In vitro human skin permeation and cutaneous metabolism of catechins from green tea extract and green tea extract-loaded chitosan microparticles[J]. International Journal of Cosmetic Science, 2011,33(6) : 572-579. doi: 10.1111/j.1468-2494.2011.00673.x
[4]	Marwah M, Perrie Y, Badhan R K S, et al. Intracellular uptake of EGCG-loaded deformable controlled release liposomes for skin cancer[J]. Journal of Liposome Research, 2019: 1-14. doi: 10.1080/08982104.2020.1748646 pmid: 32223352
[5]	Jin B S, Gwak H J . Preparation and characterization of EGCG entrapped ethosome[J]. Applied Chemistry for Engineering, 2007,18(2) : 130-135.
[6]	Xue H, Li X, Kuang C , et al. Research progress in antioxidant mechanisms of curcumin and development of antioxidant curcuminoids[J]. Food Science, 2010,31(7) : 302-307. doi: 10.7506/spkx1002-6300-201007067
[7]	Trotta M, Peira E, Carlotti M E , et al. Deformable liposomes for dermal administration of methotrexate[J]. International Journal of Pharmaceutics, 2004,270(1/2) : 119-125. doi: 10.1016/j.ijpharm.2003.10.006
[8]	Luo X, Guan R, Chen X , et al. Optimization on condition of epigallocatechin-3-gallate (EGCG) nanoliposomes by response surface methodology and cellular uptake studies in Caco-2 cells[J]. Nanoscale Research Letters, 2014,9(1) : 291. doi: 10.1186/1556-276X-9-291 pmid: 24959109
[9]	Wissing S A, Müller R H . The influence of the crystallinity of lipid nanoparticles on their occlusive properties[J]. International Journal of Pharmaceutics, 2002,242(1/2) : 377-379.
[10]	Chen W, Zou M, Ma X , et al. Co‐encapsulation of EGCG and quercetin in liposomes for optimum antioxidant activity[J]. Journal of Food Science, 2019,84(1) : 111-120. doi: 10.1111/1750-3841.14405 pmid: 30548488
[11]	Moghassemi S, Hadjizadeh A . Nano-niosomes as nanoscale drug delivery systems: an illustrated review[J]. Journal of Controlled Release, 2014,185:22-36. doi: 10.1016/j.jconrel.2014.04.015
[12]	Lu Q, Li D C, Jiang J G . Preparation of a tea polyphenol nanoliposome system and its physicochemical properties[J]. Journal of Agricultural and Food Chemistry, 2011,59(24) : 13004-13011. doi: 10.1021/jf203194w
[13]	Mandal S, Banerjee C, Ghosh S , et al. Modulation of the photophysical properties of curcumin in nonionic surfactant (Tween-20) forming micelles and niosomes: a comparative study of different microenvironments[J]. The Journal of Physical Chemistry B, 2013,117(23) : 6957-6968. doi: 10.1021/jp403724g pmid: 23682632
[14]	Li D, Martini N, Wu Z , et al. Development of an isocratic HPLC method for catechin quantification and its application to formulation studies[J]. Fitoterapia, 2012,83(7) : 1267-1274. doi: 10.1016/j.fitote.2012.06.006
[15]	Liang R, Chen L, Yokoyama W , et al. Niosomes consisting of tween-60 and cholesterol improve the chemical stability and antioxidant activity of (-)-epigallocatechin gallate under intestinal tract conditions[J]. Journal of Agricultural and Food Chemistry, 2016,64(48) : 9180-9188. doi: 10.1021/acs.jafc.6b04147 pmid: 27933988
[16]	Rashidinejad A, Birch E J, Sun-Waterhouse D , et al. Delivery of green tea catechin and epigallocatechin gallate in liposomes incorporated into low-fat hard cheese[J]. Food Chemistry, 2014,156:176-183. doi: 10.1016/j.foodchem.2014.01.115
[17]	Simon G A, Maibach H I . The pig as an experimental animal model of percutaneous permeation in man: qualitative and quantitative observations: an overview[J]. Skin Pharmacology and Physiology, 2000,13(5) : 229-234. doi: 10.1159/000029928
[18]	Klang V, Schwarz J C, Lenobel B , et al. In vitro vs. in vivo tape stripping: validation of the porcine ear model and penetration assessment of novel sucrose stearate emulsions[J]. European Journal of Pharmaceutics and Biopharmaceutics, 2012,80(3) : 604-614. doi: 10.1016/j.ejpb.2011.11.009
[19]	Marianecci C, Di Marzio L, Rinaldi F , et al. Niosomes from 80 s to present: the state of the art[J]. Advances in Colloid and Interface Science, 2014,205:187-206. doi: 10.1016/j.cis.2013.11.018
[20]	Sala M, Diab R, Elaissari A , et al. Lipid nanocarriers as skin drug delivery systems: Properties, mechanisms of skin interactions and medical applications[J]. International Journal of Pharmaceutics, 2018,535(1/2) : 1-17.
[21]	Verma D D, Verma S, Blume G , et al. Liposomes increase skin penetration of entrapped and non-entrapped hydrophilic substances into human skin: a skin penetration and confocal laser scanning microscopy study[J]. European Journal of Pharmaceutics and Biopharmaceutics, 2003,55(3) : 271-277. doi: 10.1016/s0939-6411(03)00021-3 pmid: 12754000
