两亲聚合物设计合成及其增效体系研究（VII）— 超分子体系的乳化作用

doi:10.3969/j.issn.1001-1803.2020.07.002

摘要/Abstract

摘要：

综述了近年来两亲聚合物超分子体系乳化作用的研究现状,主要包括表面活性剂增效体系、环糊精主客体包合体系以及静电作用体系的乳化特性。并总结了剪切速率和盐对超分子体系乳化性能的影响,以及3种超分子增效体系乳状液的稳定机理。为两亲聚合物超分子体系乳化的应用提供了理论基础和发展方向。

关键词: 两亲聚合物, 超分子体系, 乳化特性, 乳化机理

Abstract:

The research status of emulsification by using amphiphilic-polymer supramolecular systems in recent years has been reviewed, mainly including the emulsification characteristics of surfactant synergistic systems, cyclodextrin host-guest inclusion systems and electrostatic interaction systems. The effects of shear rate and salts on the emulsifying properties of supramolecular systems have been summarized, as well as the stability mechanism of the emulsions of three supramolecular synergistic systems. It might provide theoretical basis and development direction for the application of emulsification with amphiphilic-polymer supramolecular systems in the future.

Key words: amphiphilic polymer, supramolecular system, emulsification characteristics, emulsification mechanism

中图分类号:

TQ423

康万利,李欣欣,周博博,杨红斌,Bauyrzhan Sarsenbekuly,Saule Aidarova. 两亲聚合物设计合成及其增效体系研究（VII）— 超分子体系的乳化作用[J]. 日用化学工业, 2020, 50(7): 439-445.

KANG Wan-li,LI Xin-xin,ZHOU Bo-bo,YANG Hong-bin,Bauyrzhan Sarsenbekuly,Saule Aidarova. Study on the design and synthesis of amphiphilic polymers and their synergistic systems （VII）Emulsification with supramolecular systems[J]. China Surfactant Detergent & Cosmetics, 2020, 50(7): 439-445.

图/表 5

参考文献 38

[1]	Chen Sizhi, Liu Weidong, Wang Guijun, et al. Review of emulsion system in petroleum industry[J]. Applied Chemistry, 2017,46(7) : 1366-1369, 1373.
[2]	Wang Fengqin, Qu Zhihao, Kong Lingrong. Study on the mechanism of emulsion flooding by using micro model[J]. Petroleum Exploration and Development, 2006 ( 2) : 221-224.
[3]	Li Jerui, Liu Weidong, Zhou Yibo, et al. Review of chemical flooding and emulsification research[J]. Applied Chemistry, 2018,47(9) : 1957-1961.
[4]	Zhang Hongyan, Kang Wanli. Study on the properties of a amphiphilic polymer solution for oil displacement[J]. Contemporary Chemical Industry, 2019,48(12) : 2820-2823.
[5]	Kang Wanli, Wang Fang, Yang Hongbin, et al. Study on the design and synjournal of amphiphilic polymers and their synergistic systems (Ⅰ) : Molecular structure design of functional amphiphilic polymers[J]. China Surfactant Detergent & Cosmetics, 2020,50(1) : 8-13.
[6]	Kang Wanli, Xie Anqing, Zhou Bobo, et al. Study on the design and synjournal of amphiphilic polymers and their synergistic systems (Ⅱ): Synjournal theory and method of amphiphilic polymers[J]. China Surfactant Detergent & Cosmetics, 2020,50(2) : 86-91, 117.
[7]	Kang Wanli, Jiang Haizhuang, Kang Xin, et al. Study on the design and synjournal of amphiphilic polymers and their synergistic systems (III): Hydrophobic association[J]. China Surfactant Detergent & Cosmetics, 2020,50(3) : 149-154.
[8]	Kang Wanli, Zhang Min, Zhang Hongwen, et al. Study on the design and synjournal of amphiphilic polymers and their synergistic systems (Ⅳ) : Host guest inclusion[J]. China Surfactant Detergent & Cosmetics, 2020,50(4) : 220-226.
[9]	Kang Wanli, Li Menglan, Kang Xin, et al. Study on the design and synjournal of amphiphilic polymers and their synergistic system (V) : Electrostatic action[J]. China Surfactant Detergent & Cosmetics, 2020,50(5) : 292-298, 330.
[10]	Wang Shanger, Li Yan, Huang Xueying, et al. Supramolecular structure of a comb amphiphilic polymer[J]. Journal of Functional Polymers, 1993 ( 3) : 248-252.
[11]	Zhao Haoyang. Study on emulsification control factors and mechanism of amphiphilic polymer/surfactant system [D]. Qingdao: China University of Petroleum (East China) , 2014.
[12]	Wei Shaolong. Study on percolation characteristics of amphiphilic polymer emulsion [D]. Qingdao: China University of Petroleum (East China) , 2014.
[13]	Tan Guorong, Zhang Jian, Wang Jinben, et al. Development and field test of demulsifier for polymer surfactant flooding produced liquid [J]. Petroleum and Natural Gas Chemical Industry, 2009, 38 (5) : 418- 421, 367-368.
[14]	Liu Jianxin, Guo Yongjun, Sun Huaiyu, et al. Study on binary system of Gemini Surfactant/hydrophobically associating water soluble polymer and its application potential in tertiary oil recovery[J]. Progress in Fine Petrochemical Industry, 2009,10(6) : 11-15.
[15]	Li Xinxin, Wang Pengxinag, Hou Xiaoyu, et al. Effects of sodium chloride on rheological behaviour of the gemini-like surfactants[J]. Soft Matter, 2020,16:4024. doi: 10.1039/d0sm00243g pmid: 32270152
[16]	Wang Pengxiang, Zhu Tongyu, Hou Xiaoyu, et al. Responsive wormlike micelle with pH-induced transition of hydrotrope based on dynamic covalent bond[J]. Journal of Molecular Liquids, 2019,286:110935.
[17]	Fujita K, Nagamura S, Imoto T. Convenient preparation and effective separation of the C-2 and C-3 tosylates of α-cyclodextrin[J]. Tetrahydron Letters, 1985,25(49) : 5673-5676.
[18]	Klyamkin A A, Topchieva I N, Zubov V P. Monomolecular films of pluronic-cyclodextrin inclusion complexes at the water-gas interface[J]. Colloid and Polymer Science, 1995,273(6) : 520-523.
[19]	Osman S K, Brandl F P, Zayed G M, et al. Cyclodextrin based hydrogels: Inclusion complex formation and micellization of adamantane and cholesterol grafted polymers[J]. Polymer, 2011,52(21) : 4806-4812. doi: 10.1016/j.polymer.2011.07.059
[20]	Gosselet N M, Beucler F, Renard E, et al. Association of hydrophobically modiﬁed poly (N,N-dimethylacrylamide hydroxyethylmethacrylate) with water soluble β-cyclodextrin polymers[J]. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 1999,155(2) : 177-188.
[21]	Yu Bin, Kang Wanli, Yang Runmei, et al. Regulation of β-cyclodextrin on emulsification of hydrophobically associating polymer crude oil[J]. Science and Technology and Engineering, 2017,17(16) : 114-121.
[22]	Yu Bin. Study on performance control method and efficiency increasing mechanism of amphiphilic polymer for oil displacement [D]. Qingdao: China University of Petroleum (East China), 2017.
[23]	Ji Yanfeng, Cao Xulong, Wang Duanping, et al. Construction of inclusion system of cyclodextrin dimer and bifurcated amphiphilic polymer[J]. Polymer Materials Science and Engineering, 2017,33(7) : 45-52.
[24]	Ji Yanfeng, Kang Wanli, Meng Lingwei, et al. Study of the solution behavior of β-cyclodextrin amphiphilic polymer inclusion complex and the stability of its O/W emulsion[J]. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2014,453(1) : 117-124.
[25]	Zhang Hongwen, Yang Hongbin, Wang Fang, et al. Study on the stabilization of emulsion formed by two different inclusion complexes[J]. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2020,594.
[26]	Zhong Chuanrong, Deng Jun, Luo Pingya, et al. Molecular recombination of ionic hydrophobic association copolymers[J]. Journal of Petroleum (Petroleum Processing) , 2009,25(1) : 78-83.
[27]	Zhang Xiangfeng, Yang Hongbin, Wang Pengxiang, et al. Construction and thickening mechanism of amphiphilic polymer supramolecular system based on polyacid[J]. Journal of Molecular Liquids, 2019,286.
[28]	Ji Yanfeng, Kang Wanli, Hu Leilei, et al. Study on shearing resistance and the stability of O/W emulsion of the inclusive and hydrophobic association systems by activation energy methodology[J]. Journal of Polymer Research, 2014,21(8) : 1-9.
[29]	Du Chunan, Wang Weidong, Wang Zengbao, et al. The mechanism of cation effect on viscosity loss of polymer solution[J]. Journal of China University of Petroleum (Natural Science Edition) , 2020,44(2) : 164-168.
[30]	Ji Yanfeng. Study on β-cyclodextrin amphiphilic polymers inclusion system construction and its displacement performance[D]. Qingdao: China University of Petroleum East China) , 2015.
[31]	Xu Bin. Study on the method and mechanism of amphiphilic polymer aggregation regulation and enhanced emulsification [D]. Qingdao: China University of Petroleum (East China) , 2013.
[32]	Ji Yanfeng, Zhang Xiangfeng, Hu Leilei. Study on the synjournal of multi branched amphiphilic polymers and the emulsification of crude oil[J]. Journal of Petroleum and Chemical University, 2015,28(1) : 78-84.
[33]	Yu Bin, Kang Wanli, Fan Haiming, et al. Effect of two amphiphilic polymers on their emulsification properties[J]. China Surfactant Detergent & Cosmetics, 2016,46(10) : 565-570, 575.
[34]	Wang Chen, Li Xiaorui, Shen Yiding, et al. Interaction between ionic surfactant and hydrophobically associating polyacrylamide[J]. Functional Materials, 2012,43(23) : 3316-3321.
[35]	Lu Yao, Kang Wanli, Wu Hailong, et al. Viscosity control method of amphiphilic polymer/β-cyclodextrin inclusion system[J]. Polymer Materials Science and Engineering, 2016,32(12) : 98-103.
[36]	Lu Yao, Kang Wanli, Ji Yanfeng, et al. Study on the interaction between β-cyclodextrin/amphiphilic polymer inclusion system and sodium dodecyl sulfate [C]//Colloid and Interface Chemistry Conference of Chinese Chemical Society, 2015.
[37]	Fang Hongbo. Study on demulsification mechanism of polymer flooding produced fluid[D]. Dongying: Postdoctoral Research Station of Shengli Oilfield, 2004.
[38]	Li Fang, Wang Yongqiang, Hong Xinlin, et al. Synjournal, solution properties and interaction with cationic surfactants of anionic acrylate amphiphilic graft polymers[J]. Guangdong Chemical Industry, 2012 (3) : 13-15.
