望春花（M. biondi）花提取物缓解UVB导致皮肤损伤的作用研究

doi:10.3969/j.issn.2097-2806.2023.09.010

摘要/Abstract

摘要：

富含木兰脂素的望春花（M. biondi）花提取物（MB）被用来研究其缓解紫外线导致的皮肤损伤作用。在中波紫外线（UVB）诱导的人永生化表皮细胞（HaCaT）和以UVB诱导的HaCaT细胞培养上清液作为刺激物诱导的血管内皮细胞（HUVEC）上，通过免疫荧光染色、酶联免疫吸附法检测细胞损伤下的不同关键指标的变化。结果显示，HaCaT细胞经UVB照射后16~72 h，环丁烷嘧啶二聚体（CPD）产生量显著升高，高迁移率族蛋白B1（HMGB1）表达上升，且逐步从细胞核迁移至细胞质，热休克家族蛋白27（Hsp27）表达量也上升，同时白介素6（IL-6）、白介素8（IL-8）、前列腺素E2（PGE-2）的表达量显著增加。而HaCaT细胞培养上清液刺激HUVEC细胞24 h后，内皮素-1（ET-1）、细胞间粘附分子-1（ICAM-1）表达量均显著升高。0.1%~0.5%的MB同步处理下，可显著抑制HaCaT细胞中CPD的产生量、HMGB1的表达量，减少HMGB1的核转移，促进Hsp27的表达，降低细胞因子的表达量，同时可显著减少HUVEC细胞中的ET-1，ICAM-1表达量。因此，MB可通过降低DNA损伤，减少HMGB1的合成与核转移，减少细胞因子表达量，降低血管通透性，来缓解皮肤受到紫外线照射后的损伤作用。

关键词: 望春花（M. biondi）花提取物, 紫外线, HMGB1, ICAM-1, 皮肤损伤

Abstract:

Magnolia biondii flower extract （MB）, which is rich in magnoliol was used to study its efficacy on alleviating UVB-induced skin damage. Immunofluorescence staining and enzyme-linked immunosorbent assay were applied to detect different key biomarkers on UVB-induced keratinocytes （HaCaT） and vascular endothelial cells （HUVEC）, which induced by HaCaT cell culture supernatant after UVB stimulated for 48 h. The results show that the levels of cyclobutane pyrimidine dimer （CPD） and high mobility group box protein B1 （HMGB1） increase significantly in HaCaT cells from 16 h to 72 h after UVB irradiation, and also HMGB1 is gradually migrated from the nucleus to the cytoplasm. The expression of heat shock family protein 27 （Hsp27） also increases, as well as the cytokines such as interleukin 6 （IL-6）, interleukin 8 （IL-8）, and prostaglandin E2 （PGE-2）. Meanwhile, the expression levels of endothelin-1 （ET-1） and intercellular adhesion molecule-1 （ICAM-1） are significantly increased after HUVEC cells stimulated by cell culture supernatant for 24 h. Under the synchronous treatment of 0.1%-0.5% MB, the levels of CPD and HMGB1 in HaCaT cells are significantly inhibited, with an increase expression of Hsp27, and a decreased of the nuclear transfer of HMGB1 and cytokines. In HUVEC cells, the expression levels of ET-1and ICAM-1 are also significantly inhibited after MB treatment. Therefore, MB can alleviate the damage of skin after UV irradiation by reducing DNA damage, reducing the synthesis and nuclear transfer of HMGB1, and inhibiting the expression of cytokines and vascular permeability.

Key words: M. biondii flower extract, UV, HMGB1, ICAM-1, skin damage

中图分类号:

TQ658

黄芳, 张营, 熊玥, 周利丹, 卢伊娜. 望春花（M. biondi）花提取物缓解UVB导致皮肤损伤的作用研究[J]. 日用化学工业（中英文）, 2023, 53(9): 1065-1072.

Huang Fang, Zhang Ying, Xiong Yue, Zhou Lidan, Lu Yina. The study of Magnolia biondii flower extract in relieving UVB-induced skin damage[J]. China Surfactant Detergent & Cosmetics, 2023, 53(9): 1065-1072.

图/表 7

图 1

图 2

图 3

图 4

图 5

图 6

图 7

参考文献 24

[1]	Chen X X, Luo A L, Li J L, et al. Study on the anti- UVB-induced photoaging and damage of human dermal fibroblasts by polysacchride extract from Hyriopsis cumingii [J]. China Surfactant Detergent ＆Cosmetics, 2019, 49 (10) : 656-660.
[2]	Mullenders L H F. Solar UV damage to cellular DNA: from mechanisms to biological effects[J]. Photochem Photobiol Sci, 2018, 17 (12) : 1842-1852. doi: 10.1039/c8pp00182k
[3]	Leung W Y, Murray V. The influence of DNA methylation on the sequence specificity of UVB- and UVC-induced DNA damage[J]. J Photochem Photobiol B, 2021, 221: 112225. doi: 10.1016/j.jphotobiol.2021.112225
[4]	Petrova A, Davids L M, Rautenbach F, et al. Photoprotection by honeybush extracts, hesperidin and mangiferin against UVB-induced skin damage in SKH-1 mice[J]. J Photochem Photobiol B, 2011, 103 (2) : 126-139. doi: 10.1016/j.jphotobiol.2011.02.020
[5]	Bernard J J, Gallo R L, Krutmann J. Photoimmunology: how ultraviolet radiation affects the immune system[J]. Nat Rev Immunol, 2019, 19 (11) : 688-701. doi: 10.1038/s41577-019-0185-9 pmid: 31213673
[6]	Gallo R L, Bernard J J. Innate immune sensors stimulate inflammatory and immunosuppressive responses to UVB radiation[J]. J Invest Dermatol, 2014, 134 (6) : 1508-1511. doi: S0022-202X(15)36849-4 pmid: 24825061
[7]	Gendrisch F, Esser P R, Schempp C M, et al. Luteolin as a modulator of skin aging and inflammation[J]. Biofactors, 2021, 47 (2) : 170-180. doi: 10.1002/biof.1699 pmid: 33368702
[8]	Li X Q, Cai L M, Liu J, et al. Liquiritin suppresses UVB-induced skin injury through prevention of inflammation, oxidative stress and apoptosis through the TLR4/MyD88/NF-κB and MAPK/caspase signaling pathways[J]. Int J Mol Med, 2018, 42 (3) : 1445-1459.
[9]	Nguyen S M T, Rupprecht C P, Haque A, et al. Mechanisms governing anaphylaxis: inflammatory cells, mediators, endothelial gap junctions and beyond[J]. Int J Mol Sci, 2021, 22 (15): 7785. doi: 10.3390/ijms22157785
[10]	Tai Y C. The regulation and mechanism of the permeability of rat vascular endothelial cells via HIF-1/ET-1 pathway[D]. Hefei: Anhui Medical University, 2016.
[11]	Frank P G, Lisanti M P. ICAM-1: role in inflammation and in the regulation of vascular permeability[J]. Am J Physiol Heart Circ Physiol, 2008, 295 (3) : 926-927.
[12]	Jun A Y, Kim H J, Park K K, et al. Extract of Magnoliae Flos inhibits ovariectomy-induced osteoporosis by blocking osteoclastogenesis and reducing osteoclast-mediated bone resorption[J]. Fitoterapia, 2012, 83: 1523-1531. doi: 10.1016/j.fitote.2012.08.020
[13]	Kim H J, Nam Y R, Nam J H. Flos Magnoliae inhibits chloride secretion via ANO1 inhibition in Calu-3 cells[J]. Am. J. Chin. Med., 2018, 46: 1079-1092. doi: 10.1142/S0192415X18500568
[14]	Choi S S, Cha B Y, Choi B K, et al. Fargesin, a component of Flos Magnoliae, stimulates glucose uptake in L6 myotubes[J]. J. Nat. Med., 2013, 67: 320-326. doi: 10.1007/s11418-012-0685-4
[15]	Luo H W. Study on the chemical components and pharmacological activity of Magnolia[D]. Wuhan: South-central University for Nationalities, 2014.
[16]	Kunchana K, Jarisarapurin W, Chularojmontri L, et al. Potential use of amla (Phyllanthus emblica L.) fruit extract to protect skin keratinocytes from inflammation and apoptosis after UVB irradiation[J]. Antioxidants (Basel), 2021, 10 (5): 703.
[17]	Huang S Y, Zhou L D, Xun W, et al. Study of the anti-aging efficacy of Prunus persica(peach) resin extract[J]. China Surfactant Detergent & Cosmetics, 2022, 52 (2) : 159-165.
[18]	Jiang D D, Wang F L, Li H, et al. Promotion effects of Dragon’s Blood Complex on mitochondrial network and bioenergetics in normal human skin cells[J]. China Surfactant Detergent & Cosmetics, 2021, 51 (7) : 626-631.
[19]	Liu Y K, Zhang G S, Huang G Z, et al. Evaluation of anti-aging and anti-inflammatory effects of four bee venoms in vitro by HDF and HUVEC cell models[J]. China Surfactant Detergent & Cosmetics, 2019, 49 (10) : 668-693.
[20]	Huan Y and Helena H. Extracellular HMGB1 as a therapeutic target in inflammatory diseases[J]. Expert Opinion on Therapeutic Targets, 2018, 22 (3) : 263-277. doi: 10.1080/14728222.2018.1439924 pmid: 29447008
[21]	Murao A, Aziz M, Wang H, et al. Release mechanisms of major DAMPs[J]. Apoptosis, 2021, 26(3/4): 152-162. doi: 10.1007/s10495-021-01663-3
[22]	Cracowski J L, Roustit M. Human skin microcirculation[J]. Compr Physiol, 2020, 10 (3) : 1105-1154. doi: 10.1002/cphy.c190008 pmid: 32941681
[23]	Nakahara T, Kido-Nakahara M, Ulzii D, et al. Topical application of endothelin receptor a antagonist attenuates imiquimod-induced psoriasiform skin inflammation[J]. Sci Rep, 2020, 10 (1): 9510. doi: 10.1038/s41598-020-66490-z pmid: 32528072
[24]	Singh M, Thakur M, Mishra M, et al. Gene regulation of intracellular adhesion molecule-1 (ICAM-1): A molecule with multiple functions[J]. Immunol Lett, 2021, 240: 123-136. doi: 10.1016/j.imlet.2021.10.007 pmid: 34715236
