有机硅表面活性剂在乙醇-水体系中的起泡机制研究

doi:10.3969/j.issn.1001-1803.2021.02.001

日用化学工业 ›› 2021, Vol. 51 ›› Issue (2): 83-88.doi: 10.3969/j.issn.1001-1803.2021.02.001

• 基础研究 • 下一篇

有机硅表面活性剂在乙醇-水体系中的起泡机制研究

牛奇奇(),白艳云,台秀梅,王万绪,王国永()

中国日用化学研究院有限公司中国轻工业表面活性剂重点实验室,山西太原 030001

收稿日期:2020-04-14 修回日期:2021-01-11 出版日期:2021-02-22 发布日期:2021-02-22
通讯作者: 王国永
作者简介:牛奇奇（1994-）,山西人,硕士研究生,E-mail： 872561215@qq.com。
基金资助:
国家自然科学基金资助项目(21872088);国家重点研发计划课题资助(2017YFB0308704);伽蓝研究基金资助项目(JALA 2017)

Study of the foaming mechanism of a silicone surfactant in ethanol-aqueous system

NIU Qi-qi(),BAI Yan-yun,TAI Xiu-mei,WANG Wan-xu,WANG Guo-yong()

Key Laboratory of Surfactant of China National Light Industry, China Research Institute of Daily Chemistry Co., Ltd., Taiyuan, Shanxi 030001, China

Received:2020-04-14 Revised:2021-01-11 Online:2021-02-22 Published:2021-02-22
Contact: Guo-yong WANG

摘要/Abstract

摘要：

对有机硅表面活性剂FC-7160和几种典型的碳氢表面活性剂在50%（体积分数,下同）乙醇-水溶液中的泡沫结构、含液量和液膜的表面弹性进行了研究。结果表明,和水溶液相比,FC-7160在50%乙醇-水溶液中的气泡较小且为近圆形,且含液量较高;碳氢表面活性剂在50%乙醇-水溶液中形成的液膜扩张模量为0 mN/m,没有表面弹性,所以其泡沫产生之后立即消失;而FC-7160在50%乙醇-水溶液中的表面弹性较高,在液膜处的分子排列更为紧密,一方面增大了表面黏度,另一方面提高了液膜强度,所以其在50%乙醇-水溶液中的泡沫具有一定的稳定性。

关键词: 乙醇-水溶液, 泡沫, 表面张力, 界面弹性

Abstract:

The structure and liquid content of the foams, and the surface elasticity of films of a silicone surfactant FC-7160 and several hydrocarbon surfactants in 50% ethanol-aqueous media were studied. The results showed that, compared with the situation in water, the bubbles of FC-7160 in mixed solvent of 50% ethanol-water were smaller and nearly spherical, and the liquid content was higher; the dilatational modulus of hydrocarbon surfactants in aqueous ethanol solution were 0 mN/m, indicating that the foam films had no surface elasticity in 50% ethanol-aqueous media. However, the surface elasticity of FC-7160 in 50% ethanol-aqueous media was high, indicative of a more compact molecular arrangement which not only increased the surface viscosity but also enhanced the liquid film strength, so FC-7160 could form stable foam in the 50% ethanol-aqueous media.

Key words: ethanol-aqueous solution, foam, surface tension, interfacial elasticity

中图分类号:

TQ423

牛奇奇,白艳云,台秀梅,王万绪,王国永. 有机硅表面活性剂在乙醇-水体系中的起泡机制研究[J]. 日用化学工业, 2021, 51(2): 83-88.

NIU Qi-qi,BAI Yan-yun,TAI Xiu-mei,WANG Wan-xu,WANG Guo-yong. Study of the foaming mechanism of a silicone surfactant in ethanol-aqueous system[J]. China Surfactant Detergent & Cosmetics, 2021, 51(2): 83-88.

图/表 6

图 1

图2

图3

表1

图4

图5

参考文献 20

[1]	Bolisetty S, Peydayesh M, Mezzenga R. Sustainable technologies for water purification from heavy metals: review and analysis[J]. Chemical Society Reviews, 2019,48:463-487. doi: 10.1039/c8cs00493e pmid: 30603760
[2]	Vinogradov A V, Kuprin D S, Abduragimov I M, et al. Silica foams for fire prevention and firefighting[J]. ACS Applied Materials & Interfaces, 2016,8(1) : 294-301. pmid: 26492207
[3]	Dickinson E. Structuring of colloidal particles at interfaces and the relationship to food emulsion and foam stability[J]. Journal of Colloid and Interface Science, 2015,449:38-45. doi: 10.1016/j.jcis.2014.09.080 pmid: 25446956
[4]	Binks B P, Campbell S, Mashinchi S, et al. Dispersion behavior and aqueous foams in mixtures of a vesicle-forming surfactant and edible nanoparticles[J]. Langmuir, 2015,31(10) : 2967-2978. pmid: 25734773
[5]	Scott J L, Unali G, Perosa A. A “by-productless” cellulose foaming agent for use in imidazolium ionic liquids[J]. Chemical Communications, 2011,47(10) : 2970-2972. doi: 10.1039/c0cc05057a pmid: 21243139
[6]	Garrett P R. Defoaming: antifoams and mechanical methods[J]. Current Opinion in Colloid & Interface Science, 2015,20(2) : 81-91.
[7]	Hu X, Li Y, He X, et al. Structure-behavior-property relationship study of surfactants as foam stabilizers explored by experimental and molecular simulation approaches[J]. Journal of Physical Chemistry B, 2012,116(1) : 160-167.
[8]	Carrier V, Colin A. Coalescence in draining foams[J]. Langmuir, 2003,19(11) : 4535-4538.
[9]	Koehler S A, Hilgenfeldt S, Stone H A. A generalized view of foam drainage: experiment and theory[J]. Langmuir, 2000,16(15) : 6327-6341.
[10]	Barthel A J, Luo J, Hwang K S, et al. Boundary lubrication effect of organic residue left on surface after evaporation of organic cleaning solvent[J]. Wear, 2016,350:21-26.
[11]	Tian Xiaoman. Chemically modify on the surface of macroporous polystyrene materials[D]. Beijing: Beijing University of Chemical Technology, 2006.
[12]	Yin Yan, Zhang Yuwei. Development of alcohol disinfectants and preparations[J]. Chinese Journal of Disinfection, 2013,30(11) : 1062-1065.
[13]	Niu Qiqi, Guo Lingxiao, Wang Wanxu, et al. Foam properties of several surfactants in ethanol solution[J]. Detergent & Cosmetics, 2019,10(42) : 24-27.
[14]	Wang J, Nguyen A V, Farrokhpay S. A critical review of the growth, drainage and collapse of foams[J]. Advances in Colloid and Interface Science, 2016,228:55-70. doi: 10.1016/j.cis.2015.11.009 pmid: 26718078
[15]	Zhao G, Dai C, Zhang Y, et al. Enhanced foam stability by adding comb polymer gel for in-depth profile control in high temperature reservoirs[J]. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2015,482(3) : 115-124.
[16]	Li J, Bai Y, Wang W, et al. Green glucamine-based trisiloxane surfactant: surface activity, aggregate behavior, and superspreading on hydrophobic surfaces[J]. ACS Sustainable Chemistry & Engineering, 2019,7:4390-4398.
[17]	Georgieva D, Cagna A, Langevin D. Link between surface elasticity and foam stability[J]. Soft Matter, 2009,5(10) : 2063-2071.
[18]	Bae J E, Jung J B, Kim K, et al. A study on time-concentration superposition of dilatational modulus and foaming behavior of sodium alkyl sulfate[J]. Journal of Colloid and Interface Science, 2019,556:704-716. doi: 10.1016/j.jcis.2019.08.102 pmid: 31499441
[19]	Carey E, Stubenrauch C. Properties of aqueous foams stabilized by dodecyltrimethylammonium bromide[J]. Journal of Colloid and Interface Science, 2009,333(2) : 619-627. pmid: 19268300
[20]	Stubenrauch C, Fainerman V B, Aksenenko E V, et al. Adsorption behavior and dilational rheology of the cationic alkyl trimethylammonium bromides at the water/air interface[J]. Journal of Physical Chemistry B, 2005,109(4) : 1505-1509.

表面活性剂	临界胶束浓度/（mg·L^-1）		最低表面张力/（mN·m^-1）
表面活性剂	水溶液	50%乙醇-水溶液	水溶液	50%乙醇-水溶液
FC-7160	141.4	43.1	24.0	22.8
AES-3	191.2	—	28.0	—
AEO-9	20.8	—	30.4	—
CAB	66.5	—	27.8	—
