日用化学工业 ›› 2020, Vol. 50 ›› Issue (2): 98-106.doi: 10.3969/j.issn.1001-1803.2020.02.005

• 开发与应用 • 上一篇    下一篇

醇对微乳形成的影响以及无醇橄榄油润唇啫喱的研究

张迪1,张菁2,谭笑1,景盼盼1,叶丹1,张云澍1,田青平1()

  1. 1. 山西医科大学 药学院,山西 太原 030001
    2. 山西医科大学 法医学院,山西 太原 030001
  • 收稿日期:2019-07-22 修回日期:2020-01-15 出版日期:2020-02-22 发布日期:2020-03-04
  • 通讯作者: 田青平
  • 作者简介:张 迪(1995-),女,硕士研究生,电话:15536898218,E-mail:17732316687@163.com。
  • 基金资助:
    山西省科技厅社会发展重点研发计划项目(201803D31071);国家级大学生创新创业训练项目-甘草润唇膏的制备与开发(2019150)

Effects of alcohols on the formation of microemulsions and the study on alcohol-free olive oil lip gel

ZHANG Di1,ZHANG Jing2,TAN Xiao1,JING Pan-pan1,YE Dan1,ZHANG Yun-shu1,TIAN Qing-ping1()

  1. 1. Department of Pharmacy, Shanxi Medical University, Taiyuan, Shanxi 030001, China
    2. Department of Forensic Medicine, Shanxi Medical University, Taiyuan, Shanxi 030001, China
  • Received:2019-07-22 Revised:2020-01-15 Online:2020-02-22 Published:2020-03-04
  • Contact: Qing-ping TIAN

摘要:

通过伪三元相图绘制,油/水界面张力及微乳理化性质考察,油的组成及结构规律分析,探讨助表面活性剂(CoS)即醇对微乳形成的影响规律,并将无醇橄榄油(OL)微乳凝胶用于润唇啫喱研究。结果表明,CoS在不同油的微乳中均起到提高界面流动性,避免凝胶、液晶状态产生的作用。对不含-OH油,适当比例的CoS能够提高微乳面积;对含-OH油,可能油/水界面分子间易形成氢键,降低界面张力,提高界面稳定性,CoS的加入会竞争油/水氢键作用,不利于微乳形成。利用无醇微乳易成凝胶的特性,以m(油相)∶m(表面活性剂)=4∶6、含水量为50%的橄榄油/维生素E琥珀酸酯双连续型微乳为载体,所得润唇啫喱平均粒径为(28.31±0.45) nm、黏度为(27.4±0.632) Pa·s、pH= 5.70±0.036,外观呈粉色透明凝胶状,稳定安全;且轻薄水润、易吸收。

关键词: 微乳, 助表面活性剂, 含-OH油, 橄榄油, 润唇啫喱

Abstract:

The effects of co-surfactants (CoS), i.e. alcohols, on the formation of microemulsions were investigated by the pseudo-ternary phase diagram, the oil/water interfacial tension, the physicochemical properties of microemulsions and the analysis of composition and structure of oils. The gel based on a CoS-free olive oil microemulsion was applied for the research and development of the lip gel. The results showed that CoS could improve the interfacial fluidity of microemulsions of different structural oils to avoid gelation and liquid crystallization. For the oils without -OH, the proper proportion of CoS could expand the region of microemulsion. For the oils containing -OH, the oil/water interface might be easy to form intermolecular hydrogen bonds, which reduced interfacial tension and improved the stability of the interface, but the CoS added would compete with the oil/water hydrogen bonding, which was not conducive to the formation of the microemulsion. Taking advantage of the tendency of alcohol-free microemulsions to form gels, a bicontinuous microemulsion of olive oil-vitamin E succinate with a mass ratio of oil phase to surfactant of 4∶6 and a water content of 50% was selected as the carrier. The lip gel obtained, which was stable and safe, had the mean particle size of (28.31±0.45) nm, the viscosity of (27.4±0.632) Pa·s, the pH of 5.70±0.036, and the appearance of pink transparent gel. It was light, hydrated, and easily absorbed.

Key words: microemulsion, co-surfactant, hydroxyl-containing oil, olive oil, lip gel

中图分类号:

  • TQ423
