表面活性剂-纳米颗粒相互作用与智能体系的构建（Ⅴ）相同电荷表面活性剂-纳米颗粒相互作用（i）——超低浓度纳米颗粒/表面活性剂构建新型乳状液及其稳定机制

doi:10.3969/j.issn.1001-1803.2019.11.003

日用化学工业 ›› 2019, Vol. 49 ›› Issue (11): 711-720.doi: 10.3969/j.issn.1001-1803.2019.11.003

表面活性剂-纳米颗粒相互作用与智能体系的构建（Ⅴ）相同电荷表面活性剂-纳米颗粒相互作用（i）——超低浓度纳米颗粒/表面活性剂构建新型乳状液及其稳定机制

张婉晴¹,许茂东^1,²,蒋建中¹,崔正刚¹()

1. 江南大学化学与材料工程学院合成与生物胶体教育部重点实验室,江苏无锡 214122
2. 安微工程大学生物与化学工程学院,安徽芜湖 241000

收稿日期:2019-10-03 出版日期:2019-11-22 发布日期:2019-11-26
通讯作者: 崔正刚
作者简介:张婉晴（1995-）,女,内蒙古呼和浩特人,硕士研究生,电话：18861822963,E-mail： 1025056280@qq.com。
基金资助:
国家自然科学基金资助项目(21872064);国家自然科学基金资助项目(21573096);国家自然科学基金资助项目(21473080)

Interactions between surfactants and nanoparticles and the construction of smart systems（V） Interactions between like-charged nanoparticles and ionic surfactants（i） Construction of novel emulsions using ultra-low concentration of nanoparticles/surfactants and their stabilization mechanism

ZHANG Wan-qing¹,XU Mao-dong^1,²,JIANG Jian-zhong¹,CUI Zheng-gang¹()

1. The Key Laboratory of Synthetic and Biological Colloids, Ministry of Education, School of Chemical & Material Engineering, Jiangnan University, Wuxi, Jiangsu 214122, China
2. School of Biological and Chemical Engineering, Anhui Polytechnic University, Wuhu, Anhui 241000, China

Received:2019-10-03 Online:2019-11-22 Published:2019-11-26
Contact: Zheng-gang CUI

摘要/Abstract

摘要：

利用无机纳米颗粒在水介质中带电以及带相反电荷的离子型表面活性剂对颗粒的可逆原位疏水化作用,可以构建具有多种触发机制的Pickering乳状液和Pickering泡沫等智能分散体系。令人惊奇的是,采用无机纳米颗粒与带相同电荷的离子型表面活性剂,亦可协同稳定O/W型乳状液,其特点是所需颗粒和表面活性剂浓度极低,分别可低至0.001%和0.001cmc,其中微量表面活性剂吸附于油/水界面控制液滴大小,而纳米颗粒并不吸附于油/水界面,而是分布于连续相水膜中,相关的稳定机理难以用经典的DLVO理论、位阻稳定理论以及Pickering稳定理论来解释。为此将这种由带相同电荷的离子型表面活性剂与无机纳米颗粒协同稳定的O/W型乳状液称为新型乳状液。本讲座将简单介绍这种新型乳状液的制备、表征、普适性以及初步探索的稳定机制。

关键词: 新型乳状液, 相同电荷, 纳米Al₂O₃, 阳离子表面活性剂, 协同效应

Abstract:

By means of reversible hydrophobization of inorganic nanoparticles with the oppositely charged ionic surfactants in aqueous media, smart dispersion systems such as switchable or stimuli-responsible Pickering emulsions/foams with various triggers can be constructed. Surprisingly, like-charged inorganic nanoparticles and ionic surfactants can also co-stabilize O/W emulsions, in which the concentrations of both particles and surfactants required are extremely low, i.e., the minimum concentration required can be as low as 0.001% and 0.001cmc, respectively. It is found that trace amount of surfactants adsorb at oil/water interface controlling droplet size, whereas the nanoparticles do not adsorb at oil/water interface but distribute in aqueous lamellae of the continuous phase. The O/W emulsions co-stabilized by like-charged nanoparticles and ionic surfactants are called novel emulsions since their stabilization mechanism can not be well interpreted by the classic DLVO, the steric and the Pickering stabilization theories. This lecture will discuss the formation, characterization, universality and preliminary stabilization mechanism of the novel O/W emulsions.

Key words: novel emulsion, same charge, alumina nanoparticle, cationic surfactant, synergistic effect

中图分类号:

TQ423

张婉晴,许茂东,蒋建中,崔正刚. 表面活性剂-纳米颗粒相互作用与智能体系的构建（Ⅴ）相同电荷表面活性剂-纳米颗粒相互作用（i）——超低浓度纳米颗粒/表面活性剂构建新型乳状液及其稳定机制[J]. 日用化学工业, 2019, 49(11): 711-720.

ZHANG Wan-qing,XU Mao-dong,JIANG Jian-zhong,CUI Zheng-gang. Interactions between surfactants and nanoparticles and the construction of smart systems（V） Interactions between like-charged nanoparticles and ionic surfactants（i） Construction of novel emulsions using ultra-low concentration of nanoparticles/surfactants and their stabilization mechanism[J]. China Surfactant Detergent & Cosmetics, 2019, 49(11): 711-720.

图/表 14

图1

图2

图3

图4

图5

图6

图7

图8

图9

图10

图11

图12

图13

图14

参考文献 30

[1]	Saji T, Hoshino K, Aoyagui S . Reversible formation and disruption of micelles by control of the redox state of the head group[J]. J. Am. Chem. Soc., 1985,107:6865-6868.
[2]	Dexter A F, Malcolm A S, Middelberg A P J . Reversible active switching of the mechanical properties of a peptide film at a fluid-fluid interface[J]. Nature Mater., 2006,5:502-506.
[3]	Eastoe J, Sánchez-Dominguez M, Wyatta P , et al. A photo-responsive organogel[J]. Chem. Commun., 2004, 2608-2609.
[4]	Li L, Rosenthal M, Zhang H , et al. Light-switchable vesicles from liquid-crystalline homopolymer-surfactant complexes[J]. Angew. Chem. Int. Ed., 2012,51:11616-11619.
[5]	Liu Y X, Jessop P G, Cunningham M , et al. Switchable surfactants[J]. Science, 2006,313:958-960.
[6]	Jiang J, Zhu Y, Cui Z , et al. Switchable Pickering emulsions stabilized by silica nanoparticles hydrophobized in situ with a switchable surfactant[J]. Angew. Chem. Int. Ed., 2013,52:12373-12376.
[7]	Liang C, Liu Q X, Xu Z H . Surfactant-free switchable emulsions using CO₂-responsive particles[J]. ACS Appl. Mater. Interfaces, 2014,6:6898-6904.
[8]	Tang J, Quinlan P J, Tam K C . Stimuli-responsive Pickering emulsions: Recent advances and potential applications[J]. Soft Matter, 2015,11:3512-3529.
[9]	Zhu Y, Jiang J Z, Liu K H , et al. Switchable Pickering emulsions stabilized by silica nanoparticles hydrophobized in situ with a conventional cationic surfactant[J]. Langmuir, 2015,31:3301-3307.
[10]	Zhu Y, Pei X, Jiang J , et al. Responsive aqueous foams stabilized by silica nanoparticles hydrophobized in situ with a conventional surfactant[J]. Langmuir, 2015,31:12937-12943.
[11]	Xu M D, Zhang W Q, Pei X M , et al. CO₂/N₂ triggered switchable Pickering emulsions stabilized by alumina nanoparticles in combination with a conventional anionic surfactant[J]. RSC Advances, 2017,7:29742-29751.
[12]	Liu K H, Jiang J Z, Cui Z G , et al. pH-Responsive Pickering emulsions stabilized by silica nanoparticles in combination with a conventional zwitterionic surfactant[J]. Langmuir, 2017,33:2296-2305.
[13]	Despert G, Oberdisse J . Formation of micelle-decorated colloidal silica by adsorption of nonionic surfactant[J]. Langmuir, 2003,19:7604-7610.
[14]	Notley S M . Adsorption of nonionic surfactants with ethylene oxide headgroup chemistry at the titania-water interface[J]. J. Phys. Chem. B, 2012,116:6059-6064.
[15]	Zhu Y, Fu T, Liu K H , et al. Thermo-responsive Pickering emulsions stabilized by silica nanoparticles in combination with alkyl polyoxyethylene ether nonionic surfactant[J]. Langmuir, 2017: 5724-5733.
[16]	Arab D, Kantzas A, Bryant S L . Nanoparticle stabilized oil in water emulsions: a critical review[J]. J. Petrol. Sci. Eng., 2018,163:217-242.
[17]	Aveyard R, Binks B, Fletcher P D I , et al. Contact angles in relation to the effects of solids on film and foam stability[J]. J. Disper. Sci. Technol., 1994,15(3):251-271.
[18]	Sun Q, Li Z, Wang J , et al. Aqueous foam stabilized by partially hydrophobic nanoparticles in the presence of surfactant[J]. Colloids and Surfaces A, 2015,471:54-64.
[19]	Xu M D, Jiang J Z, Pei X M , et al. Novel oil-in-water emulsions stabilized by ionic surfactant and similarly charged nanoparticles at very low concentrations[J]. Angew. Chem. Int. Ed., 2018,130:7864-7868.
[20]	Xu M D, Xu L F, Lin Q , et al. Switchable oil-in-water emulsions stabilized by like-charged surfactant and particles at very low concentration[J]. Langmuir, 2019,35:4058-4067.
[21]	Khosravani S, Alaei M, Rashidi A M , et al. O/W emulsions stabilized with γ-alumina nanostructures for chemical enhanced oil recovery[J]. Materials Research Bulletin, 2013,48(6) : 2186-2190.
[22]	Xu M D . Study on the fluid-fluid dispersion systems stabilized by Al₂O₃ nanoparticles in combination with surfactants and their stimuli-responsive properties[D]. Wuxi: Jiangnan University, 2019.
[23]	Yang F, Liu S, Xu J , et al. Pickering emulsions stabilized solely by layered double hydroxides particles: The effect of salt on emulsion formation and stability[J]. J. Colloid Interf. Sci., 2006,302(1):159-169.
[24]	Binks B P, Rodrigues J A . Enhanced stabilization of emulsions due to surfactant-induced nanoparticle flocculation[J]. Langmuir, 2007,23:7436-7439.
[25]	Becher P . Encyclopedia of Emulsion Technology[M]. Vol 1, Basic Theory. New York: Marcel Dekker, 1983.
[26]	Rosen M J, Kunjappu J T . Surfactants and interfacial phenomena[M]. 4 ^th edition. Hoboken, Wiley , 2012.
[27]	Ma H, Luo M X, Dai L L . Influences of surfactant and nanoparticles assembly on effective interfacial tensions[J]. Phys. Chem. Chem. Phys., 2008,10:2207-2213.
[28]	Haffner B, Khidas Y, Pitois O . Flow and jamming of granular suspensions in foams[J]. Soft Matter, 2014,10:3277-3283.
[29]	Khidas Y, Haffner B, Pitois O . Capture-induced transition in foamy suspensions[J]. Soft Matter, 2014,10:4137-4141.
[30]	Rouyer F, Haffner B, Louvet N , et al. Foam clogging[J]. Soft Matter, 2014,10:6990-6998.
