基于聚集诱导发光现象检测十二烷基三甲基溴化铵

doi:10.3969/j.issn.1001-1803.2021.12.001

摘要/Abstract

摘要：

阳离子表面活性剂对土壤和水系微生物具有明显的毒性,快捷而灵敏的阳离子表面活性剂分析检测方法是监控阳离子表面活性剂排放的重要工具,而利用聚集诱导发光（AIE）现象分析检测表面活性剂是一种新兴的快捷方法。但是,尚未见有基于AIE现象分析阳离子表面活性剂的报导。为此,利用一种水溶性的AIE探针1,1,2,2-四[4-（3-磺酸丙氧基）苯基]乙烯盐（TSTPE）并以十二烷基三甲基溴化铵（DTAB）为模型物,建立了基于AIE现象检测水体中DTAB的“turn-on”荧光分析方法。结果表明：游离的TSTPE在水中只有微弱的荧光发射;与DTAB以静电相互作用结合后,其荧光发射强度（F）显著增强,并且随DTAB浓度（c）增加而进一步地增强;当TSTPE的浓度为4.5×10^-5 mol/L时,F与c的线性响应范围约为1.05×10^-4~1.7×10^-4 mol/L,检测限约为5.7×10^-7 mol/L;在pH为3~10范围内TSTPE-DTAB混合体系的荧光发射具有较好的稳定性,NaCl,KCl和NaNO₃三种无机盐对TSTPE-DTAB混合体系的荧光发射干扰较小,在模拟水样中DTAB的回收率不低于95%。

关键词: 荧光探针, 聚集诱导发光, 检测, 阳离子表面活性剂

Abstract:

Cationic surfactants have obvious toxicity to microorganisms in soil and water. Methods for fast and sensitive analysis and detection of cationic surfactants are important tools for monitoring the discharge of cationic surfactants. Aggregation-induced emission （AIE） phenomenon analysis is an emerging and fast method to detect surfactants. However, the analysis of cationic surfactants based on AIE phenomenon has not been reported. Therefore, a “turn-on” fluorescence method for detecting dodecyltrimethylammonium bromide （DTAB） in water was established by using a water-soluble AIE probe, 1, 1, 2, 2-tetrakis[4-（3-sulfonatopropoxyl）phenyl] ethylene salt （TSTPE）, and using DTAB as the model. The results showed that free TSTPE was only weakly emissive in water; after binding with DTAB by electrostatic interaction, its fluorescence emission intensity （F） was significantly enhanced and was further increased with the increase of DTAB concentration （c）. When the concentration of TSTPE was 4.5×10 ^-5 mol/L, the linear response range of F vs. c was around 1.05×10 ^-4~1.7×10^-4 mol/L, and the detection limit was approximately 5.7×10^-7mol/L. The fluorescence emission of TSTPE-DTAB mixed system had good stability in the pH range of 3~10; three inorganic salts, NaCl, KCl and NaNO₃, had little interference with the fluorescence emission of the TSTPE-DTAB mixture, and the recovery rate of DTAB in simulated water samples was not less than 95%.

Key words: fluorescent probe, aggregation-induced emission, detection, cationic surfactant

中图分类号:

TQ423

孙庆,方银军,刘雪锋. 基于聚集诱导发光现象检测十二烷基三甲基溴化铵[J]. 日用化学工业, 2021, 51(12): 1163-1170.

Sun Qing,Fang Yinjun,Liu Xuefeng. Detection of dodecyltrimethylammonium bromide based on aggregation-induced emission phenomenon[J]. China Surfactant Detergent & Cosmetics, 2021, 51(12): 1163-1170.

图/表 6

图 1

图 2

图 3

图 4

图 5

表 1

参考文献 24

[1]	Guo Xiangfeng, Jia Lihua. Cationic surfactants and their applications [M]. Beijing: Chemical Industry Press, 2002.
[2]	Shcherbakova V A, Laurinavichius K S, Akimenko V K. Toxic effect of surfactants and probable products of their biodegradation on methanogenesis in an anaerobic microbial community[J]. Chemosphere, 1999, 39(11) : 1861-1870. pmid: 10533717
[3]	Scott, Vane G. Spectrophotometric determination of cationic surfactants with Orange Ⅱ[J]. Analytical Chemistry, 1968, 40(4) : 768-773. doi: 10.1021/ac60260a038
[4]	Nitschke L, Müller R, Metzner G, et al. Trace analysis of cationic surfactants in water using HPLC with conductometric detection[J]. Fresenius’ Journal of Analytical Chemistry, 1992, 342(9) : 711-713. doi: 10.1007/BF00321861
[5]	Ding W H, Tsai P C. Determination of alkyltrimethylammonium chlorides in river water by gas chromatography/ion-trap mass spectrometry with electron-impact and chemical ionization[J]. Anal Chem, 2003, 75(8) : 1792-1797. doi: 10.1021/ac020536y
[6]	Liu J, Wang X, Wang L. Spectrofluorimetric assay of cationic surfactants by fluorescence quenching of 9-anthracenecarboxylic acid[J]. Microchimica Acta, 2005, 151(1/2) : 123-126.
[7]	Su Fengyi, Xing Xinhui. Concentration characterization of quaternary ammonium surfactants by FITC[J]. Journal of Chemical Industry and Engineering, 2008, 59(10) : 2589-2595.
[8]	Xu Y, Zhang S, Qian X, et al. A supramolecular off-on fluorescent switch and implication logic gate for detection of cationic surfactant[J]. Journal of Fluorescence, 2011, 21(3) : 1015-1020. doi: 10.1007/s10895-010-0792-0
[9]	An B K, Kwon S K, Jung S D, et al. Enhanced emission and its switching in fluorescent organic nanoparticles[J]. Journal of the American Chemical Society, 2002, 124(48) : 14410-14415. doi: 10.1021/ja0269082
[10]	Hong Y N, Lam J W Y, Tang B Z. Aggregation-induced emission phenomenon mechanism and applications[J]. Chemical Communications, 2009, 29:4332-4353.
[11]	Mei J, Leung N L C, Kwok R T K, et al. Aggregation-induced emission: together we shine, united we soar![J]. Chemical Reviews, 2015, 115(21) : 11718-11940. doi: 10.1021/acs.chemrev.5b00263 pmid: 26492387
[12]	Gao M, Wang L C, Chen J J, et al. Aggregation-induced emission active probe for light-up detection of anionic surfactants and wash-free bacterial imaging[J]. Chemistry-A European Journal, 2016, 22(15) : 5107-5112. doi: 10.1002/chem.201505202
[13]	Gao T, Cao X Z, Dong J, et al. A novel water soluble multifunctional fluorescent probe for highly sensitive and ultrafast detection of anionic surfactants and wash free imaging of Gram-positive bacteria strains[J]. Dyes and Pigments, 2017, 143(1) : 436-443. doi: 10.1016/j.dyepig.2017.05.006
[14]	Zhou Z, Li X, Zhang Y, et al. Aggregation-induced-emission (AIE) directed assembly of a novel responsive nanoprobe for dual targets sensing[J]. Materials Science and Engineering C, 2019, 99:1092-1098. doi: 10.1016/j.msec.2019.02.068
[15]	Feng A Q, Jiang F R, Huang G Y, et al. Synjournal of the cationic fluorescent probes for the detection of anionic surfactants by electrostatic self-assembly[J]. Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy, 2020, 224:117446. doi: 10.1016/j.saa.2019.117446
[16]	Zhu Q H, Huang L, Su J R, et al. A sensitive and visible fluorescence-turn-on probe for the CMC determination of ionic surfactants[J]. Chemical Communications, 2014, 50(9) : 1107-1109. doi: 10.1039/C3CC45244A
[17]	Cai X T, Yang W J, Huang L, et al. A series of sensitive and visible fluorescence-turn-on probes for CMC of ionic surfactants: design, synjournal, structure influence on CMC and sensitivity, and fast detection via a plate reader and a UV light[J]. Sensors and Actuators B: Chemical, 2015, 219:251-260. doi: 10.1016/j.snb.2015.04.126
[18]	Duan X F, Zeng J, Lü J W, et al. A facile synjournal of tetraarylethenes via cross McMurry Coupling between diaryl ketones[J]. ChemInform, 2007, 38(5) : 713-718.
[19]	Tong H, Hong Y, Dong Y, et al. Protein detection and quantitation by tetraphenylethene-based fluorescent probes with aggregation-induced emission characteristics[J]. The Journal of Physical Chemistry B, 2007, 111(40) : 11817-11823. doi: 10.1021/jp073147m
[20]	Li Y M, Hu X L, Tian S D, et al. Polyion complex micellar nanoparticles for integrated fluorometric detection and bacteria inhibition in aqueous media[J]. Biomaterials, 2014, 35(5) : 1618-1626. doi: 10.1016/j.biomaterials.2013.10.077
[21]	Xu Jingou, Wang Zunben. Fluorescence analysis [M]. Beijing: Science Press, 2006.
[22]	Mello J C D, Wittmann H F, Friend R H. An improved experimental determination of external photoluminescence quantum efficiency[J]. Advanced Materials, 1997, 9(3) : 230-232. doi: 10.1002/(ISSN)1521-4095
[23]	Ministry of Health of the People’s Republic of China. Standards for drinking water quality: GB 5749 — 2006[S]. Beijing: China Standard Press, 2006.
[24]	Nakahara Y, Kida T, Nakatsuji Y, et al. New fluorescence method for the determination of the critical micelle concentration by photosensitive monoazacryptand derivatives[J]. Langmuir, 2005, 21(15) : 6688-6695. pmid: 16008375

样品	加标量/（mol·L^-1）	加标后测定值/（mol·L^-1）	回收率/%	相对标准偏差/%
超纯水	1.2×10^-4	（1.195 2±0.003 2）×10^-4	99.60±0.27	0.27
	1.4×10^-4	（1.389 7±0.002 0）×10^-4	99.19±0.14	0.14
	1.6×10^-4	（1.587 4±0.004 4）×10^-4	99.21±0.27	0.27
模拟水	1.2×10^-4	（1.179 9±0.003 9）×10^-4	98.32±0.33	0.33
	1.4×10^-4	（1.367 2±0.005 0）×10^-4	97.66±0.37	0.37
	1.6×10^-4	（1.540 9±0.007 3）×10^-4	96.30±0.48	0.48
