天然生物质材料的制备、性质与应用（Ⅰ）——自然界唯一的碱性多糖：甲壳素/壳聚糖

doi:10.3969/j.issn.1001-1803.2022.01.002

摘要/Abstract

摘要：

甲壳素是自然界除纤维素之外的第二大天然生物材料,也是自然界唯一的碱性多糖。甲壳素及其脱乙酰基衍生物壳聚糖因为分子结构中存在着氨基、羟基、乙酰氨基、糖苷键等多种活性基团,可发生多种化学反应以制得具有特定性质和用途的功能材料,在医药卫生、环境保护、纺织印染、造纸、食品及日用化工等多个行业中得到广泛应用。本文阐述了甲壳素、壳聚糖的名称、结构和来源,以及常规生产方法、理化性质和近期的应用进展情况,并指出了甲壳素、壳聚糖及其衍生物当前存在的问题和发展方向。

关键词: 甲壳素, 壳聚糖, 碱性多糖, 衍生物, 制备, 性质, 应用

Abstract:

Chitin is the second most abundant naturally occurring biological material after cellulose, as well as the unique alkaline polysaccharide in nature. Chitin, and its deacetylated derivative, chitosan, i.e., a linear copolymer of β-（1→4）-linked 2- acetamido-2-deoxy-β-D-glucopyranose and 2-amino-2-deoxy-β-D-glucopyranose, offer an excellent set of characteristics as functional materials: biocompatibility, biodegradability to harmless products, high bioavailability, nontoxicity, physiological inertness, antibacterial properties, heavy metal ions chelation, gel forming properties and hydrophilicity, and remarkable affinity to protein and tissue. Due to the presence of amino, hydroxyl, acetyl amino groups and glycosidic bonds in the molecules of chitin and chitosan, many special functional derivatives can be produced by schiff base modification, carboxylation, alkylation, acylation, quaternization, graft copolymerization, cross-linking, and degradation. Owing to these unique characteristics and excellent functions, chitin, chitosan and their derivatives have been widely used in various industrial fields, such as pharmaceutical industry, environmental protection, textile printing and dyeing, paper making, food, tissue engineering, enzyme immobilization, and daily-use chemical industries. Herein, the name, structure and origin of chitin and chitosan, as well as the conventional production methods, physical and chemical properties and current application status of chitin, chitosan and their derivatives, were introduced.

Key words: chitin, chitosan, basic polysaccharide, derivative, preparation, property, application

中图分类号:

TQ658

隋振全,毛金超,徐桂云,范金石. 天然生物质材料的制备、性质与应用（Ⅰ）——自然界唯一的碱性多糖：甲壳素/壳聚糖[J]. 日用化学工业, 2022, 52(1): 7-14.

Sui Zhenquan,Mao Jinchao,Xu Guiyun,Fan Jinshi. Preparation, properties and applications of natural biomass materials (Ⅰ) The unique alkaline polysaccharide in nature: chitin/chitosan[J]. China Surfactant Detergent & Cosmetics, 2022, 52(1): 7-14.

图/表 5

图 1

图 2

表 1

图 3

图 4

参考文献 47

[1]	Sun Chenglei. Research progress on extraction technology of chitin from shrimp shell[J]. Modern Food, 2021 (18) : 41-43.
[2]	Kaczmarek M B, Struszczyk-Swita K, Li X, et al. Enzymatic modifications of chitin, chitosan, and chitooligosaccharides[J]. Frontiers in Bioengineering and Biotechnology, 2019, 7:243. doi: 10.3389/fbioe.2019.00243 pmid: 31612131
[3]	Ding S, Wang Y, Li J, et al. Progress and prospects in chitosan derivatives: modification strategies and medical applications[J]. Journal of Materials Science & Technology, 2021, 89:209-224.
[4]	Zhu K Y, Merzendorfer H, Zhang W, et al. Biosynjournal, turnover, and functions of chitin in insects[J]. Annual Review of Entomology, 2016, 61:177-196. doi: 10.1146/ento.2016.61.issue-1
[5]	Hahn T, Tafi E, Paul A, et al. Current state of chitin purification and chitosan production from insects[J]. Journal of Chemical Technology and Biotechnology, 2020, 95(11) : 2775-2795.
[6]	Younes I, Rinaudo M. Chitin and chitosan preparation from marine sources. structure, properties and applications[J]. Marine Drugs, 2015, 13(3) : 1133-1174. doi: 10.3390/md13031133 pmid: 25738328
[7]	Chen Yimiao, Xu Zhaoxu, Si Xingyu, et al. Study on chitin preparation from shrimp shells in huanghua[J]. Food Research and Development, 2021, 42(12) : 163-170.
[8]	Chen Meng, Lan Xiaowei, Bai Yun, et al. Optimization of microwave assisted alkaline preparation of chitosan by response surface methodology[J]. The Food Industry, 2021, 42(9) : 94-98.
[9]	Zhang Yankun, Liu Guozhong. The preparation and application of chitin, chitosan and their derivatives[J]. China Surfactant Detergent & Cosmetics 1998 (4) : 36-40.
[10]	Cen Xinyan. Application of chitosan derivatives in printing and dyeing wastewater[J]. Modern Chemical Research, 2017 (4) : 71-72.
[11]	Dai Peng, Zheng Jinlu, Liu Bingrong, et al. Chemical modification and application of chitin and chitosan[J]. Polymer Bulletin, 2020 (7) : 1-17.
[12]	Wang W, Xue C, Mao X. Chitosan: structural modification, biological activity and application[J]. International Journal of Biological Macromolecules, 2020, 164:4532-4546. doi: 10.1016/j.ijbiomac.2020.09.042
[13]	Jimtaisong A, Saewan N. Utilization of carboxymethyl chitosan in cosmetics[J]. International Journal of Cosmetic Science, 2014, 36(1) : 12-21. doi: 10.1111/ics.12102 pmid: 24152381
[14]	Cao Xiaohua, Xiao Duo. Measure of sunscreen cream transmittance in uv wave range and analysis of sun protection effect[J]. Spectroscopy and Spectral Analysis, 2013, 33(11) : 3098-3100. pmid: 24555389
[15]	Gao Duan, Ye Ping, Wang Yan, et al. Preliminary development of sunscreen containing moutain honeysuckle and wild chrysanthemum flower[J]. Guangzhou Chemical Industry, 2020, 48(22) : 104-107.
[16]	Casadidio C, Peregrina D V, Gigliobianco M R, et al. Chitin and chitosans: characteristics, eco-friendly processes, and applications in cosmetic science[J]. Marine Drugs, 2019, 17(6) : 369. doi: 10.3390/md17060369
[17]	Libio I C, Demori R, Ferrao M F, et al. Films based on neutralized chitosan citrate as innovative composition for cosmetic application[J]. Materials Science & Engineering C-Materials for Biological Applications, 2016, 67:115-124.
[18]	Rajashree S, Rose C. Studies on an anti-aging formulation prepared using aloe vera blended collagen and chitosan[J]. International Journal of Pharmaceutical Sciences and Research, 2018, 9(2) : 582-588.
[19]	Dutta P K, Dutta J, Tripathi V S. Chitin and chitosan: chemistry, properties and applications[J]. Journal of Scientific & Industrial Research, 2004, 63:20-31.
[20]	Brigham C J. Chitin and chitosan: sustainable, medically relevant biomaterials[J]. International Journal of Biotechnology for Wellness Industries, 2017, 6(2) : 41-47. doi: 10.6000/1927-3037.2017.06.02.1
[21]	Sionkowska A, Kaczmarek B, Michalska M, et al. Preparation and characterization of collagen/chitosan/hyaluronic acid thin films for application in hair care cosmetics[J]. Pure and Applied Chemistry, 2017, 89(12) : 1829-1839. doi: 10.1515/pac-2017-0314
[22]	Azuma K, Koizumi R, Izawa H, et al. Hair growth-promoting activities of chitosan and surface-deacetylated chitin nanofibers[J]. International Journal of Biological Macromolecules, 2019, 126:11-17. doi: 10.1016/j.ijbiomac.2018.12.135
[23]	Husain S, Al-Samadani K H, Najeeb S, et al. Chitosan biomaterials for current and potential dental applications[J]. Materials, 2017, 10(6) : 602. doi: 10.3390/ma10060602
[24]	Chen C Y, Ying-Chien C. Antibacterial effect of water-soluble chitosan on representative dental pathogens streptococcus mutans and lactobacilli brevis[J]. Journal of Applied Oral Science, 2012, 20(6) : 620-627. doi: 10.1590/S1678-77572012000600006
[25]	Rahmani F, Moghadamnia A A, Kazemi S, et al. Effect of 0.5% chitosan mouthwash on recurrent aphthous stomatitis: a randomized double-blind crossover clinical trial[J]. Electron Physician, 2018, 10(6) : 6912-6919. doi: 10.19082/6912
[26]	Mohire N C, Yadav A V. Chitosan-based polyherbal toothpaste: as novel oral hygiene product[J]. Indian Journal of Dental Research, 2010, 21(3) : 380-384. doi: 10.4103/0970-9290.70808 pmid: 20930349
[27]	Verkaik M J, Busscher H J, Jager D, et al. Efficacy of natural antimicrobials in toothpaste formulations against oral biofilms in vitro[J]. Journal of Dentistry, 2011, 39(3) : 218-224. doi: 10.1016/j.jdent.2010.12.007
[28]	Carvalho T S, Lussi A. Combined effect of a fluoride-, stannous- and chitosan-containing toothpaste and stannous-containing rinse on the prevention of initial enamel erosion-abrasion[J]. Journal of Dentistry, 2014, 42(4) : 450-459. doi: 10.1016/j.jdent.2014.01.004
[29]	Cazón P, Vázquez M. Mechanical and barrier properties of chitosan combined with other components as food packaging film[J]. Environmental Chemistry Letters, 2020, 18(2) : 257-267. doi: 10.1007/s10311-019-00936-3
[30]	Dong Caiwen, Tang Jiuting, Duan Mengmeng, et al. Optimization of the clarification technology of okra juice with chitosan by responsesurface methodology[J]. Hubei Agricultural Sciences, 2016, 55(22) : 5922-5925, 5930.
[31]	Wu T, Ge Y, Li Y, et al. Quality enhancement of large yellow croaker treated with edible coatings based on chitosan and lysozyme[J]. International Journal of Biological Macromolecules, 2018, 120(Pt A) : 1072-1079. doi: 10.1016/j.ijbiomac.2018.08.188
[32]	Yao Jieyu, Li Yuan, Jiang Yangyang, et al. Optimization of chitosan-citrus essential oil microcapsules for application in the preservation of litopenaeus vannamei [J]. Progress in Fishery Sciences, 2019, 40(6) : 203-209.
[33]	Yong H, Wang X, Zhang X, et al. Effects of anthocyanin-rich purple and black eggplant extracts on the physical, antioxidant and pH-sensitive properties of chitosan film[J]. Food Hydrocolloids, 2019, 94:93-104. doi: 10.1016/j.foodhyd.2019.03.012
[34]	Ye W, Liu L, Yu J, et al. Hypolipidemic activities of partially deacetylated alpha-chitin nanofibers/nanowhiskers in mice[J]. Food & Nutrition Research, 2018, 62.
[35]	Pal P, Pal A, Nakashima K, et al. Applications of chitosan in environmental remediation: a review[J]. Chemosphere, 2021, 266:128934.
[36]	Li Zhenxing, Kang Xiaowen, Huang Xiaoyan. Preparation of shell polysaccharide-based adsorbent and its adsorption performance to heavy metal ions[J]. Mining and Metallurgical Engineering, 2021, 41(3) : 143-146, 150.
[37]	Su Saisai, Li Jia. Treatment of wastewater containing zinc by chitosan-activated sludge composite adsorbent[J]. Energy and Energy Conservation, 2018 (11) : 90-91.
[38]	Meng Fengshu, Zhang Hongxiang, Chen Qian, et al. Preparation and characterization of chitosan/quaternized polyvinyl alcohol composite for anion exchange membrane[J]. New Chemical Materials, 2018, 46(8) : 115-118.
[39]	Che Qiuling, Li Mingchun, Xin Meihua. Research progress of chitosan and its derivatives in natural fabric finishing[J]. Chemical Industry and Engineering Progress, 2018, 37(11) : 4330-4336.
[40]	Hao L, Wang R, Fang K, et al. The modification of cotton substrate using chitosan for improving its dyeability towards anionic microencapsulated nano-pigment particles[J]. Industrial Crops and Products, 2017, 95:348-356. doi: 10.1016/j.indcrop.2016.10.043
[41]	Lu Y H, Liu Z M, Cheng D H. Preparation of hydroxypropyl chitosan nanoparticles and their application in antheraea pernyi silk treatment[J]. Advanced Materials Research, 2013, 796:380-384. doi: 10.4028/www.scientific.net/AMR.796
[42]	Mohebbi S, Nezhad M N, Zarrintaj P, et al. Chitosan in biomedical engineering: a critical review[J]. Current Stem Cell Research & Therapy, 2019, 14(2) : 93-116.
[43]	Feng C, Wang Z, Jiang C, et al. Chitosan/o-carboxymethyl chitosan nanoparticles for efficient and safe oral anticancer drug delivery: in vitro and in vivo evaluation[J]. International Journal of Pharmacology, 2013, 457(1) : 158-167.
[44]	Guo Liangliang, Jin Ningning, Wang Ying, et al. Preparation of N-alkylated chitosan/bletilla striata polysaccharide composites[J]. Applied Chemical Industry, 2020, 49(3) : 632-637.
[45]	Song Z, Li G, Guan F, et al. Application of chitin/chitosan and their derivatives in the papermaking industry[J]. Polymers, 2018, 10(4) : 389. doi: 10.3390/polym10040389
[46]	Sabazoodkhiz R, Rahmaninia M, Ramezani O. Interaction of chitosan biopolymer with silica nanoparticles as a novel retention/drainage and reinforcement aid in recycled cellulosic fibers[J]. Cellulose, 2017, 24(8) : 3433-3444. doi: 10.1007/s10570-017-1345-3
[47]	Khantayanuwong S, Khemarom C, Salaemae S. Effects of shrimp chitosan on the physical properties of handsheets[J]. Agriculture and Natural Resources, 2017, 51(1) : 53-56. doi: 10.1016/j.anres.2016.07.006

类别	种类	含量
节肢动物	甲壳纲（如虾、蟹）	58%~85%
	昆虫纲（如蝗、蝶、蚊、蝇）	20%~60%
	蛛形纲（如蜘蛛、蝎、螨）	4%~22%
软体动物	双神经纲（如石鳖）	3%~26%
	腹足纲（如鲍、蜗牛）
	掘足纲（如角贝）
	瓣鳃纲（如蚶、牡蛎）
	头足纲（如乌贼）
环节动物	原环虫纲（如角蜗虫）	有的含甲壳素极少,高的含有20%~38%
	毛足纲（如沙蚕、蚯蚓）
	蛭纲（如蚂蟥）
原生动物	鞭毛虫纲（如锥体虫）	含甲壳素较少
	肉足虫纲（如变形虫）
	纤毛虫纲（加革履虫）
	孢子虫纲（如原虫）
腔肠动物	水螅虫纲（如中水螅、筒螅）	一般含甲壳素很少,但有的可达3%~30%
	钵水母纲（如海月水母、海蛰、霞水母）
	珊瑚虫纲
海藻	绿藻	含少量甲壳素
真菌	子囊菌、担子茵、藻茵等	从微量到45%不等
其他	动物的关节、蹄、足的坚硬部分,以及动物肌肉与骨接合处
