高效液相色谱法同时测定化妆品原料甘草提取液中甘草苷和甘草酸

doi:10.3969/j.issn.1001-1803.2021.03.013

日用化学工业 ›› 2021, Vol. 51 ›› Issue (3): 250-255.doi: 10.3969/j.issn.1001-1803.2021.03.013

高效液相色谱法同时测定化妆品原料甘草提取液中甘草苷和甘草酸

杨红美¹(),徐嘉琪¹,龚盛昭^1,²(),余涓^1,³

1.广州环亚化妆品科技有限公司,广东广州 510663
2.广东轻工职业技术学院,广东广州 510300
3.广东环亚美容化妆品博物馆,广东广州 510663

收稿日期:2020-06-16 修回日期:2021-03-03 出版日期:2021-03-22 发布日期:2021-03-23
通讯作者: 龚盛昭
作者简介:杨红美（1990-）,女,分析研究员,硕士,电话：18675349627,E-mail：hongmeiapple19@163.com。
基金资助:
广州市科技计划项目资助(201604016111);广州市科学技术协会学术融合经费类资助(X20200501017)

Simultaneous determination of liquiritin and glycyrrhizic acid by high performance liquid chromatography in licorice extract in raw materials of cosmetics

YANG Hong-mei¹(),XU Jia-qi¹,GONG Sheng-zhao^1,²(),YU Juan^1,³

1. Guangzhou Uniasia Cosmetic Technology Co., Ltd., Guangzhou, Guangdong 510663, China
2. Guangdong Industry Technical College, Guangzhou, Guangdong 510300, China
3. Guangdong Huanya Beauty and Cosmetics Museum, Guangzhou, Guangdong 510663, China

Received:2020-06-16 Revised:2021-03-03 Online:2021-03-22 Published:2021-03-23
Contact: Sheng-zhao GONG

摘要/Abstract

摘要：

选取甘草提取液中典型有效成分甘草苷和甘草酸,建立其高效液相色谱检测方法。样品用质量分数为50%乙醇提取,以Agilent ZORBAX SB-C₁₈ （4.6 mm×250 mm×5 μm）为分析柱,乙腈-0.05%磷酸梯度洗脱,流速1.0 mL/min,检测波长237 nm。结果表明,该方法测试时间短,测试结果准确;在0.5~100 μg/mL范围内线性良好,相关系数均大于0.999 5; 空白样品中加标回收率为91.47%~114.57%,相对标准偏差为0.87%~3.32%。该方法准确、可靠,适用于化妆品原料甘草提取液中甘草苷和甘草酸的测定。

关键词: 化妆品原料, 甘草苷, 甘草酸, 高效液相色谱法

Abstract:

A comprehensive analytical method based on high performance liquid chromatography （HPLC） was developed for the determination of liquiritin and glycyrrhizic acid in licorice extract in cosmetics. The target compounds were extracted with 50% ethanol, separated on a Agilent ZORBAX SB-C₁₈ column （4.6 mm×250 mm×5 μm） in gradient elution program using acetonitrile and 0.05% phosphoric acid as mobile phases, at flow rate of 1 mL/min, and detection wavelength of 237 nm. The method had a short test time and accurate test results, it showed good linear relationship between 0.5-100 μg/mL with correlation coefficients larger than 0.999 5. The spiked recoveries in the blank sample were in the range of 91.47%-114.57% with the relative standard deviations of 0.87%-3.32%. The results indicate that the developed method is rapid, accurate and reliable, which is suitable for the determination of liquiritin and glycyrrhizic acid in licorice extract in cosmetics.

Key words: cosmetics raw materials, liquiritin, glycyrrhizic acid, high performance liquid chromatography （HPLC）

中图分类号:

TQ658

杨红美,徐嘉琪,龚盛昭,余涓. 高效液相色谱法同时测定化妆品原料甘草提取液中甘草苷和甘草酸[J]. 日用化学工业, 2021, 51(3): 250-255.

YANG Hong-mei,XU Jia-qi,GONG Sheng-zhao,YU Juan. Simultaneous determination of liquiritin and glycyrrhizic acid by high performance liquid chromatography in licorice extract in raw materials of cosmetics[J]. China Surfactant Detergent & Cosmetics, 2021, 51(3): 250-255.

图/表 7

表 1

图 1

表 2

图 2

图 3

表 3

图 4

参考文献 13

[1]	Fang Yan, Sun Zhiyuan, Gao Yuan, et al. Comparison of liquiritin and glycyrrhizic acid contents in liquorice root before and after stir-frying[J]. Journal of Changchun University of Chinese Medicine 2020,36(3). http://kns.cnki.net/kcms/detail/22.1375.R.20200430.1535.010.html. doi: 10.1186/s13020-018-0202-0 pmid: 30159006
[2]	Cui Fenglin, Zhang Taijun, Li Tao, et al. Study on the liquorice ingredients in cosmetics[J]. Detergent & Cosmetics, 2017,40(3) ：19-22.
[3]	Wang Baiqiang, Zeng Xiaojun. Study on inhibitory activity against tyrosinase and manufacture of skin-whitening cosmetics[J]. The Light & Textile Industries of Fujian, 2002 (7) ：1-6.
[4]	Zhao Yaxin, Gao Wenyuan, Zhang Lianxue, et al. Application of glycyrrhiza uralensis in cosmetics[J]. Flavour fragrance cosmetics, 2010,8(4) ：45-48.
[5]	Wang Jianguo, Zhou Zhong, Liu Haifeng, et al. The new application of glycyrrhiza to cosmetics[C]// Processings of China Cosmetics Academic Seminar in 2002. Shanghai: China Association of Fragrance Flavour and Cosmetic Industries, 2002：257-260.
[6]	National Medical Products Administration. Safety and technical standards for cosmetics[S]. Beijing: China Standards Press, 2015.
[7]	Zhou Yuemei, Feng Chao, Shi Yuhua, et al. Study on fingerprint of licorice extract and the content determination of its multi-indicator[J]. Chinese Journal of Modern Applied Pharmacy, 2020,37(9) ：1046-1051.
[8]	Zhang Lijuan, Wang Yingying, Li Fei. A comparative study on the contents of glycyrrhizin and other five components in glycyrrhiza uralensis from different origins[J]. Journal of Wenshan University, 2019,32(6) ：24-27.
[9]	Hou Xiaojing, Song Zhaohui, Han Yuanyuan, et al. Simultaneous determination of liquiritin, naringin and ammonium glycyrrhetate in Susu Xiaoerzhike granules by HPLC[J]. Tianjin Pharmacy, 2019,31(6) ：8-11.
[10]	Chinese Pharmacopoeia Commission. Chinese pharmacopoeia （volume Ⅰ）[S]. Beijing: China Medical Science Press, 2015,87.
[11]	Peng Qing, Meng Shuo, Miao Lan, et al. Simultaneous determination of nine components in scutellariae radix-glycyrrhizae radix et rhizoma pair by HPLC wavelength switching method[J]. Chinese Journal of Information on Traditional Chinese Medicine, 2020,27(5) ：65-69.
[12]	Liu Ting, He Kaiyong, Lan Jing, et al. Simultaneous determination of four components in codonopsis radix colla corii asini pill by RP-HPLC[J]. Herald of Medicine, 2018,37(10) ：1251-1255.
[13]	Lu Yaqi, Luo Hanyan, Wang Lixia, et al. Analysis on content change and transformation rule of main characteristic components in stir-frying process of glycyrrhizae radix et rhizoma[J]. Chinese Journal of Experimental Traditional Medical Formulae, 2020,26(10) ：100-106.

组分	线性范围/（μg·mL^-1）	线性回归方程	相关系数（r²）
甘草苷	0.5~100	y=14.759x+3.810	0. 999 9
甘草酸	0.5~100	y=5.583x+1.168	0. 999 8

	加入量/（μg·mL^-1）	实测值/（μg·mL^-1）	加标回收率/%	平均回收率/%	RSD/%
甘草苷	1	1.15	115	111.50	3.25
		1.16	116
		1.11	111
		1.08	108
		1.07	107	111.50	3.25
		1.12	112	111.50	3.25
甘草苷	10	11.55	115.5	114.57	1.54
		11.45	114.5
		11.63	116.3
		11.60	116.0
		11.17	111.7
		11.34	113.4
	20	22.21	111.05	112.38	0.87
		22.48	112.40
		22.58	112.90
		22.63	113.15
		22.27	111.35
		22.68	113.40
甘草酸	1	0.95	95	92.17	3.32
		0.97	97
		0.90	90
		0.91	91
		0.90	90
		0.90	90
	10	9.20	92.0	91.47	1.43
		9.0	90.0
		9.0	90.0
		9.34	93.4
		9.19	91.9
		9.15	91.5
	20	19.34	96.70	97.66	1.96
		19.63	98.15
		19.61	98.05
		19.79	98.95
		19.95	99.75
		18.87	94.35
