生育酚纳米乳液的制备及性能研究

doi:10.3969/j.issn.2097-2806.2023.12.007

摘要/Abstract

摘要：

为提高α-生育酚（α-Toc）的稳定性和活性，利用超分子包合机理制备纳米乳液，得到了一种稳定性好、透皮效果佳、抗氧化性能优异的α-Toc纳米传递载体。考察了聚山梨醇酯（Tween）的种类、羟丙基-β-环糊精（HP-β-CD）的添加量和α-Toc溶液的添加量对纳米乳液粒径的影响，并借助傅里叶红外光谱、透射电子显微镜、纳米粒度分析仪、热重分析仪和Franz扩散池研究了α-Toc纳米乳液的包埋情况和性能评价。结果表明，所制备的α-Toc超分子纳米乳液的粒径小且分布均匀，在0 ℃和室温条件下具有良好的储藏稳定性。纳米乳液可以显著增强α-Toc的热稳定性，比未经过包裹的α-Toc具有更优异的抗氧化能力，纳米乳液在化妆品配方中可有效促进α-Toc的透皮吸收。

关键词: α-生育酚, 纳米乳液, 超分子, 性能研究

Abstract:

To improve the stability and activity of α-tocopherol （α-Toc）, a nanoemulsion was prepared by supramolecular inclusion method, which was a kind of nanocarrier for α-Toc with good stability, good transdermal effect and excellent anti-oxidation. The effects of the types of polysorbates （Tweens）, the amount of hydroxypropyl β-cyclodextrin （HP-β-CD） and the amount of α-Toc solution on the particle size of the nanoemulsion were investigated. The encapsulation condition and performance evaluation of α-Toc nanoemulsion were studied by Fourier infrared spectroscopy, transmission electron microscopy, nanoparticle size analysis, thermogravimetric analysis and Franz diffusion cell method. The results showed that the obtained α-Toc supramolecular nanoemulsion had small particle size and uniform distribution and had good storage stability both at 0 ℃ and room temperature. This nanoemulsion could significantly enhance the thermal stability of α-Toc, and it showed better antioxidant capacity than the nonencapsulated α-Toc. The nanoemulsion could also effectively promote the transdermal absorption of α-Toc in cosmetic formula. This work could provide research basis for the application of nanocarriers in the field of daily-use chemical industry.

Key words: α-tocopherol, nano-emulsion, supramolecule, performance study

中图分类号:

TQ658

蔡国强, 徐雯雯, 权琰, 潘卫, 张蕾, 何一波. 生育酚纳米乳液的制备及性能研究[J]. 日用化学工业（中英文）, 2023, 53(12): 1405-1411.

Guoqiang Cai, Wenwen Xu, Yan Quan, Wei Pan, Lei Zhang, Yibo He. Preparation and properties of α-tocopherol nanoemulsions[J]. China Surfactant Detergent & Cosmetics, 2023, 53(12): 1405-1411.

图/表 10

表 1

图 1

表 2

图 2

图 3

图 4

图 5

表 3

图 6

图 7

参考文献 21

[1]	Galli F, Azzi A, Birringer M, et al. Vitamin E: Emerging aspects and new directions[J]. Free Radical Biology and Medicine, 2017, 102: 16-36. doi: S0891-5849(16)30432-4 pmid: 27816611
[2]	Niki E. Role of vitamin E as a lipid-soluble peroxyl radical scavenger: in vitro and in vivo evidence[J]. Free Radical Biology and Medicine, 2014, 66: 3-12. doi: 10.1016/j.freeradbiomed.2013.03.022 pmid: 23557727
[3]	Ribeiro A M, Estevinho B N, Rocha F. The progress and application of vitamin E encapsulation: A review[J]. Food Hydrocolloids, 2021, 121: 106998. doi: 10.1016/j.foodhyd.2021.106998
[4]	Liu X, Wu J, Wang M, et al. Progress of cosmetic delivery system: Application of new drug dosage forms and new technology in cosmetics[J]. Flavour Fragrance Cosmetics, 2021 (6) : 99-105.
[5]	Arruda T R, Marques C S, Soares N F F. Native cyclodextrins and their derivatives as potential additives for food packaging: A review[J]. Polysaccharides, 2021, 2 (4) : 825-842. doi: 10.3390/polysaccharides2040050
[6]	Periasamy R. A systematic review on the significant roles of cyclodextrins in the construction of supramolecular systems and their potential usage in various fields[J]. Journal of Carbohydrate Chemistry, 2020, 39 (5-6) : 189-216. doi: 10.1080/07328303.2020.1792919
[7]	Ogoshi T, Harada A. Chemical sensors based on cyclodextrin derivatives[J]. Sensors, 2008, 8 (8) : 4961-4982. pmid: 27873795
[8]	Ueda H. Physicochemical properties and complex formation abilities of large-ring cyclodextrins[J]. Journal of Inclusion Phenomena and Macrocyclic Chemistry, 2002, 44 (1) : 53-56. doi: 10.1023/A:1023055516398
[9]	Huang J, Yang Y, Yu H, et al. Research progress of supramolecular self-assembly inclusion mechanism of cyclodextrin[J]. Food Science, 2022: 1-16.
[10]	Xiao Z, Zhang Y, Niu Y, et al. Cyclodextrins as carriers for volatile aroma compounds: A review[J]. Carbohydrate Polymers, 2021, 269: 118292. doi: 10.1016/j.carbpol.2021.118292
[11]	Gorjian H, Mihankhah P, Khaligh N G. Influence of tween nature and type on physicochemical properties and stability of spearmint essential oil (Mentha spicata L.) stabilized with basil seed mucilage nanoemulsion[J]. Journal of Molecular Liquids, 2022, 359: 119379. doi: 10.1016/j.molliq.2022.119379
[12]	Kaur G, Mehta S K. Developments of polysorbate (Tween) based microemulsions: Preclinical drug delivery, toxicity and antimicrobial applications[J]. International Journal of Pharmaceutics, 2017, 529 (1) : 134-160. doi: 10.1016/j.ijpharm.2017.06.059
[13]	Hashizaki K, Kageyama T, Inoue M, et al. Study on preparation and formation mechanism of n-Alkanol/Water emulsion using a-cyclodextrin[J]. Chemical and Pharmaceutical Bulletin, 2007, 55 (11) : 1620-1625. doi: 10.1248/cpb.55.1620
[14]	Xiao Z, Liu Y, Niu Y, et al. Cyclodextrin supermolecules as excellent stabilizers for Pickering nanoemulsions[J]. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2020, 588: 124367. doi: 10.1016/j.colsurfa.2019.124367
[15]	Mathapa B G, Paunov V N. Self-assembly of cyclodextrin-oil inclusion complexes at the oil-water interface: a route to surfactant-free emulsions[J]. Journal of Materials Chemistry A, 2013, 1 (36) : 10836-10846. doi: 10.1039/c3ta12108a
[16]	De Oliveira V E, Almeida E W C, Castro H V, et al. Carotenoids and β-cyclodextrin inclusion complexes: Raman spectroscopy and theoretical investigation[J]. The Journal of Physical Chemistry A, 2011, 115 (30) : 8511-8519. doi: 10.1021/jp2028142
[17]	Galvão J G, Silva V F, Ferreira S G, et al. β-cyclodextrin inclusion complexes containing Citrus sinensis (L.) Osbeck essential oil: An alternative to control Aedes aegypti larvae[J]. Thermochimica Acta, 2015, 608: 14-19. doi: 10.1016/j.tca.2015.04.001
[18]	Tadros T, Izquierdo P, Esquena J, et al. Formation and stability of nano-emulsions[J]. Advances in Colloid and Interface Science, 2004, 108-109: 303-318.
[19]	Capek I. Preparation of metal nanoparticles in water-in-oil (W/O) microemulsions[J]. Advances in Colloid and Interface Science, 2004, 110 (1) : 49-74. doi: 10.1016/j.cis.2004.02.003
[20]	Wang Y, Liang R, Luo Y. Preparation and transdermal properties of ceramide nanoemulsions[J]. China Surfactant Detergent & Cosmetics, 2021, 51 (10) : 949-955.
[21]	Cao Q, Wang Q, Wang X, et al. Preparation and characterization of sea-buckthorn oil nanofibers encapsulated by electrospinning[J]. Food Science, 2022, 43 (9) : 48-54.

组分名称	V/μL
组分名称	试剂1	试剂2	试剂3
待测样品	100	—	100
DPPH溶液	100	100	—
无水乙醇	—	100	100

试剂名称	分子式	HLB值	疏水基团	cmc值/（mmol/L）
T20	C₅₈H₁₁₄O₂₆	16.7	C12	0.049 9
T40	C₆₂H₁₂₂O₂₆	15.6	C16	0.033 3
T60	C₆₄H₁₂₆O₂₆	14.9	C18	0.016 7
T80	C₅₈H₁₂₄O₂₆	15.0	C18	0.015 0

组分名称	w/%
组分名称	含包封α-Toc的纳米乳液	含未包封的α-Toc纯品
去离子水	To 100	To 100
卡波姆	0.3	0.3
甘油	3	3
矿油	8	8
硬脂酸甘油酯，PEG-100硬脂酸酯	2	2
鲸蜡硬脂醇	1	1
α-Toc溶液	－	0.5
α-Toc纳米乳液	12.5	－
NaOH	0.08	0.08
苯氧乙醇	1.5	1.5
