基于牛血清白蛋白LB膜模板诱导蜂巢状碱式碳酸锌薄膜生长研究

doi:10.3969/j.issn.2097-2806.2024.12.004

日用化学工业（中英文） ›› 2024, Vol. 54 ›› Issue (12): 1431-1436.doi: 10.3969/j.issn.2097-2806.2024.12.004

基于牛血清白蛋白LB膜模板诱导蜂巢状碱式碳酸锌薄膜生长研究

王海威^1,^3,^*(),肖文波¹,贾秀玲^2,³,肖洋¹,杜祖亮³

1.南昌航空大学科技学院，江西南昌 330034
2.南京工业职业技术大学，江苏南京 210036
3.河南大学材料学院，河南开封 475004

收稿日期:2024-01-17 修回日期:2024-11-28 出版日期:2024-12-22 发布日期:2024-12-25
基金资助:
国家自然科学基金资助项目(21203055);国家自然科学基金资助项目(12064027);江西省教育厅科学技术研究项目(GJJ2204302);江西省教育厅科学技术研究项目(GJJ2204305);江西省高层次高技能领军人才培养工程入选(2022-63号);九江市市级科技计划项目（自然科学基金、创新人才）(2022-2023年)

Study on the growth of honeycomb-like film of basic zinc carbonate induced by bovine serum albumin LB film template

Haiwei Wang^1,^3,^*(),Wenbo Xiao¹,Xiuling Jia^2,³,Yang Xiao¹,Zuliang Du³

1. Nanchang Hangkong University, Science and Technology College, Nanchang, Jiangxi 330034, China
2. Nanjing Vocational University of Industry Technology, Nanjing, Jiangsu 210036, China
3. School of Materials, Henan University, Kaifeng, Henan 475004, China

Received:2024-01-17 Revised:2024-11-28 Online:2024-12-22 Published:2024-12-25
Contact: * E-mail: highwei01@126.com.

摘要/Abstract

摘要：

以牛血清白蛋白（BSA）这种可溶性生物大分子蛋白为模板，在室温下成功制备了多孔蜂巢状碱式碳酸锌薄膜。经过低温退火后得到了具有良好电子迁移率的高比表面积多孔ZnO薄膜。经SEM、TEM、XRD、光致发光光谱和紫外-可见吸收光谱等测量手段，分别对碱式碳酸锌薄膜及其退火后的ZnO薄膜进行表面形貌、结晶性能以及光致发光特性分析。通过对无蛋白质薄膜诱导所得的样品进行比较，判断BSA分子与Zn²⁺离子之间的络合作用是碱式碳酸锌多孔薄膜合成的首要因素。实验表明该方法制备的ZnO薄膜样品具有高比表面积和在近紫外范围的宽带发光特性。

关键词: 仿生矿化, 碱式碳酸锌薄膜, 蜂巢状结构, 光电化学特性

Abstract:

Honeycomb-like films of basic zinc carbonate were successfully prepared on FTO （SnO₂: F） conductive glass using bovine serum albumin （BSA） as a template at room temperature. After low-temperature annealing, a high-specific-surface-area porous ZnO film with excellent electron mobility was obtained. The surface morphology, crystallization performance, and photoluminescence characteristics of basic zinc carbonate thin films and annealed ZnO thin film were analyzed by scanning electron microscopy （SEM）, transmission electron microscopy （TEM）, X-ray diffraction （XRD）, photoluminescence spectroscopy （PL） and UV-Visible spectroscopy （UV-vis）. By comparing with those samples prepared without any protein, it was determined that the complexation between BSA molecules and Zn²⁺ ions was the primary factor in the synthesis of porous films of basic zinc carbonate. The experimental results showed that the ZnO thin film samples prepared with this method had high specific surface area and broadband luminescence characteristics in the near ultraviolet range.

Key words: biomimetic mineralization, basic zinc carbonate film, honeycomb structure, photoelectrochemical properties

中图分类号:

TQ031

王海威, 肖文波, 贾秀玲, 肖洋, 杜祖亮. 基于牛血清白蛋白LB膜模板诱导蜂巢状碱式碳酸锌薄膜生长研究[J]. 日用化学工业（中英文）, 2024, 54(12): 1431-1436.

Haiwei Wang, Wenbo Xiao, Xiuling Jia, Yang Xiao, Zuliang Du. Study on the growth of honeycomb-like film of basic zinc carbonate induced by bovine serum albumin LB film template[J]. China Surfactant Detergent & Cosmetics, 2024, 54(12): 1431-1436.

图/表 7

图1

图2

图3

图4

图5

图6

图7

参考文献 25

[1]	Chang Xiangling, Chai Fei. Preparation and performance study of zinc oxide nanocomposite antibacterial materials[J]. China Surfactant Detergent & Cosmetics, 2023, 53 (9) : 1051-1056.
[2]	Lv Yiyan, Zhan Qiwei, Yu Xiaoniu. Microbial-Induced mineralization of zinc ions based on the degradation of toluene and its characterization[J]. Science of Advanced Materials, 2021, 4 (13) : 656-661.
[3]	Xia Juan, Liu Xiaopin, GaoYunhong, et al. Green synthesis of Ag/ZnO microplates by doping Ag ions on basic zinc carbonate for fast photocatalytic degradation of dyes[J]. Environmental Technology, 2020, 27 (41) : 3584-3590.
[4]	Zhang Feng, Xu Zhilong, Wang Kun, et al. Controllable preparation of ZnO porous flower through a membrane dispersion reactor and their photocatalytic properties[J]. Chinese Journal of Chemical Englneering, 2018, 26: 2192-2198.
[5]	Levine K E, Collins B J, Stout M D, et al. Characterization of zinc carbonate basic as a source of zinc in a rodent study investigating the effects of dietary deficiency or excess[J]. Analytical Letters, 2017, 15 (50) : 2447-2464.
[6]	Bai Yang, Wang Zhenhua, Li Xiangbo, et al. Corrosion behavior of low pressure cold sprayed Zn-Ni composite coatings[J]. Journal of Alloys and Compounds, 2017, 719: 194-202.
[7]	Xin Chunyu, Hu Maocong, Wang Kang, et al. Significant enhancement of photocatalytic reduction of CO₂ with H₂O over ZnO by the formation of basic zinc carbonate[J]. Langmuir, 2017, 27 (33) : 6667-6676.
[8]	Xu Zezhong, Cao Xianzhi, Yang Zhihui, et al. Synthesis of multilayered zinc carbonate hydroxide microcrystals and its removal Cu²⁺ properties[J]. Journal of Synthetic Crystals, 2018, 47 (11) : 2384-2388.
[9]	Wang Weibing. Experimental study on effects of process conditions on the yield of basic zinc carbonate[J]. Shandong Chemical Industry, 2022, 51 (4) :18-20.
[10]	Su Xiaoli, Zuo Guoqiang, Cai Tiancong, et al. Research on preparation of nanometer zinc oxide with specific grain size by thermal decomposition of basic zinc carbonate and mechanism thereof[J]. Inorganic Chemicals Industry, 2017, 49 (8) : 37-40.
[11]	Yan Qiaozhi, Lu Hengzhi, Liu Dongxiao. Preparation of zinc carbonate hydroxide coating on aluminum surface and its superhydrophobic properties after modification[J]. Materials for Mechanical Engineering, 2013, 37 (12) : 64-70.
[12]	Yang Yongbin, Zhang Xin, Li Qian. Characteristics of crystallization behavior of basic zinc carbonate in preparation by ammonia process[J]. Mining And Metallurgical Engineering, 2013, 33 (2) :101-104.
[13]	Zhang Linjin, Chen Limei, Chen Chuanhui, et al. Preparation on ultrafine basic zinc carbonate by hydrolysis-precipitation process[J]. Inorganic Chemicals Industry, 2013, 45 (1) : 27-29.
[14]	Wang Haiwei, Liu Haoguang, Zeng Huiping, et al. Synthesis of large-area compact ZnO thin films and its photoelectrochemical properties[J]. Journal of Functional Materials, 2018, 49 (2) : 2001-2005. doi: 10.3969/j.issn.1001-9731.2018.02.001
[15]	Wang Haiwei, Liu Haoguang, Wu Lei, et al. Study on the induction of petal shaped lithium carbonate crystallization by BSA LB film[J]. Journal of Functional Materials, 2018, 49 (4) : 4193-4196. doi: 10.3969/j.issn.1001-9731.2018.04.036
[16]	Wang Haiwei, Wu Lei, Liu Haoguang, et al. Thin films formation of cobalt hydroxynitrate under a bovine serum albumin Langmuir monolayer combined with ammonia vapor diffusion[J]. Journal of Functional Materials, 2018, 49 (8) : 8009-8013. doi: 10.3969/j.issn.1001-9731.2018.08.002
[17]	Wang Haiwei, Liu Haoguang, Li Haiyan, et al. Thin films formation of zinc hydroxide nitrate under a behenic acid Langmuir monolayer combined with ammonia vapor diffusion[J]. Materials Review, 2014, 28 (7) : 19-23.
[18]	Wang Haiwei, Liu Haoguang, Zeng Huiping, et al. Thin films formation of zinc hydroxide nitrate under a protein bovine serum albumin Langmuir monolayer combined with ammonia vapor diffusion[J]. Journal of Materials Science & Engineering, 2016, 34 (6) : 967-971.
[19]	Kitano Yasushi. The behaviors of various inorganic ions in the separation of calcium carbonate from a bicarbonate solution[J]. J. Chem. Soc., 1962, 35 (11) : 1973-1980.
[20]	Giuseppe S, Daniel V. Understanding the formation of PbSe honeycomb superstructures by dynamics simulations[J]. Physical Review X, 2019: 1-32.
[21]	Mann S. Molecular recognition in biomineralization[J]. Nature, 1988, 332 (10) : 119-124.
[22]	DiMasi E, Seo Y K, Pichon B P, et al. Structural adaptability in an organic template for CaCO₃mineralization[J]. CrystEngComm, 2007, 9 (12) : 1192-1204.
[23]	Qi Junjie, Xu Minxuan, Hu Xiaofeng, et al. Frabrication and properties of self-powered ultraviolet detectors based on one-demensional ZnO nanomaterials[J]. Acta Phys. Sin., 2015, 64 (17).
[24]	Gao Song, Zhao Suling, Xu Zheng, et al. Near ultraviolet luminescence characteristics of ZnO nanoparticle film[J]. Acta Phys. Sin., 2014, 63 (15).
[25]	Zheng Youliao, Wu Ling, Sheng Bo, et al. Third generation semiconductor materials[M]. Beijing: China Railway Press, 2017.
